Corbin Russwin 1060-118-A62-6-L4 626 6P Conventional Mortise Cylinder Instructions
Corbin Russwin 1060-118-A62-6-L4 626 6P Conventional Mortise CYL offers a robust and reliable solution for your locking needs. With a standard master ring mortise cylinder measuring 1-1/8″ in length, this product features a straight cam design and a 6-pin configuration, ensuring compatibility with a variety of locking systems. The L4 keyway enhances security, while the satin chrome finish not only provides a sleek appearance but also durability in commercial environments. Designed for easy rekeying, the interchangeable core allows for quick changes by non-technical personnel without the need to remove the hardware from the door. This feature is especially beneficial in high-traffic areas like office buildings, hotels, schools, and hospitals, where convenience and efficiency are paramount. The 1060 model integrates seamlessly with Corbin Russwin’s 8000 Series interchangeable cores, offering flexibility and long-term cost savings. All operating keys-change, master, and grand master-function normally, while a special control key enables rekeying with minimal effort. This cylinder is an ideal choice for those seeking a combination of security, convenience, and practical application across various facilities. For enhanced security, consider utilizing temporary construction cores as recommended by Corbin Russwin.
6P Conventional Mortise CYL
Standard Master Ring Mortise Cylinder, 1-1/8″ Length, Straight Cam, 6 Pin, L4 Keyway, Satin Chrome Finish
Corbin Russwin Interchangeable Core Mortise and Rim Housings are made from soldi brass and are available to accept Corbin Russwin 8000 Series Interchangeable Cores in 6 or 7-Pin versions.
Interchangeable cores provide rekeying convenience for virtually all types of keying systems.
Interchangeable cores like thissavetime and money over the life of a building.
- Advantages
Rekeying can be done by non-technical personnel without removing hardware from the door. When used system wide, IC provides tremendous rekeying convenience. When planned from the inception of a system, IC cylinders can be integrated with conventional cylinders.
- Applications
IC is recommended for virtually all types of keying systems, such as office buildings, hotels, schools, hospitals and universities. When used in exit devices and other installations which are labor intensive to rekey, IC saves time and money over the life of the building.
- Operations
All operating keys (change, master, grand master) operate the lock normally. To rekey, use the special control key. The control key operates at a separate shear line in certain chambers within the core. Only the control key is required to remove and install a core.
- Cores
Cores are available in 6-pin (standard), 7-pin, security and Pyramid.
- Construction Keying
Corbin Russwin recommends temporary construction cores for greater security. Special construction master keying is also available, when planned from the inception of the keying system.
- Core Marking
Concealed Key Control (CKC) is available for all Corbin Russwin cores.
Attributes
Cam Number: A62
Cam Type: Straight
Commercial Residential: Commercial
Cylinder Length: 1-1/8″
Cylinder Type: Mortise Cylinder
Finish: 626/US26D
Finish Family: Matte Silver
Installation: Commercial
Pack Qty: 1
Pins: 6
Series: Interchangeable Core Cylinders
Std Keyway: L4
Subtype: Mortise Cylinder
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- Interchangeable Core Cylinders Cut Sheet
- Key Systems Catalog
- Video: Interchangeable Core Installation
