Description
NGP 137SA 72″ Anodized Aluminum Silicone Bulb Perimeter Seal
NGP 137SA 72″ Anodized Aluminum Silicone Dense Bulb Perimeter Seal offers an exceptional solution for ensuring airtight and moisture-resistant seals in commercial restroom partitions. Crafted from Aluminum Alloy 6063 with a T5 temper, this perimeter seal is designed for durability and long-lasting performance. It features a dense silicone bulb made from synthetic rubber polymer (Siloxane), providing excellent flexibility and memory, allowing it to maintain its shape in harsh conditions. This product is flame-resistant and boasts impressive resistance to ozone, UV rays, and aging, making it ideal for environments where fire safety is paramount. It is recommended for areas utilizing FM200 or Halon fire suppression systems, and it meets BHMA certification to ANSI/BHMA A156.22 performance tests for heat and cold. The NGP 137SA seal operates effectively within a temperature range of -100°F to 500°F, remaining flexible even in extreme temperatures. It comes with #6 x 3/4″ stainless steel sheet metal screws for easy installation, with slotted screw holes allowing for adjustment. Additionally, it features a sleek anodized aluminum finish that complements any restroom design. Choose the NGP 137SA perimeter seal for reliable performance and superior protection in your commercial restroom applications.
72″ Anodized Aluminum Silicone Dense Bulb Perimeter Seal
- Flame-Resistant
- Aluminum Alloy 6063, T5 Temper
- Moisture-Resistant
- Dense Silicone is Black
- Temperature Range -100°F to 500°F, Remains Flexible at Extreme Temperatures
- Excellent Flexibility and Memory
- BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
- Anodized Aluminum
- Excellent Resistance to Ozone, UV and Aging
- #6 x 3/4″ Stainless Steel Sheet Metal Screws Furnished
- Synthetic Rubber Polymer: Siloxane
- Recommended for Areas Using FM200 or Halon Fire Suppression Systems
- Screw Holes Slotted for Adjustment
Attributes
Application: Excellent Flexibility and Memory
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Dense Silicone is Black
Fasteners: #6 x 3/4″ Stainless Steel Sheet Metal Screws Furnished
Finish: Anodized Aluminum
Fire Rated: Recommended for Areas Using FM200 or Halon Fire Suppression Systems
Length: 72.0″
Material: Synthetic Rubber Polymer: Siloxane
Moisture Resistant: YES
Resistance: Excellent Resistance to Ozone, UV and Aging
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE – CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: ACOUSTICAL TESTED to ASTM E90 Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements, and ASTM E2235 Standard Test Method for Determination of Decay Rates for use in Sound Insulation Test Methods. Refer to information on pages G8 thru G10 of our Gasketing catalog for test result data.
Standard-4: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-5: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature Range -100°F to 500°F, Remains Flexible at Extreme Temperatures
