Lifesafety Power M8P-BOXED 8 Output Managed Lock Distribution Module, Class 2 Power Limited for OR/WA
Lifesafety Power Inc M8P-BOXED 8 Output Managed Lock Distribution Module is a cutting-edge solution designed to meet the stringent power requirements for access control systems, particularly in Oregon and Washington. This Class 2 power limited module features eight monitored and controlled voltage outputs, all accessible via a network or the internet, ensuring seamless integration into modern security setups. The M8P-BOXED is equipped with eight control inputs, supporting both voltage and dry contact activation, along with programmable outputs that can be tailored for fail-safe or fail-secure operations. Its dual voltage capability allows for versatile application, with visual indicators to easily verify output voltage levels-green for 12V and blue for 24V. Engineered for efficiency, the M8 boasts a fiberglass PCB for enhanced environmental performance and is compliant with RoHS standards. Each output can be individually managed through a user-friendly browser interface, providing real-time monitoring of voltage and current, as well as the ability to set trigger alerts for any deviations. With a maximum input current of 20 Amps and robust fire alarm interfaces, the Lifesafety Power M8P-BOXED module is the ideal choice for professionals seeking reliable performance in access control applications.
8 Output Managed Lock Distribution Module, Class 2 Power Limited, Required by Code for OregonWashington
Notice: The info below is not item specific.
The M8 smart power controller communicates with an NL4 or NLX network module and provides eight (8) monitored and controlled voltage outputs accessible from a network or the internet. Optional RS485 connection for remote monitoring by NLX using RSMOD (not included). The M8 provides eight (8) control inputs capable of voltage or dry contact activation and eight (8) controlled and monitored outputs, with each output network programmable for fail-safe, fail-secure, fire alarm over ride, and AC loss over ride for egress lock control. Each output is also programmable to either of two voltages available when used in a dual voltage iSCAN power system. OutSmart dual color LEDs visually indicate voltage levels by output (green for 12V, blue for 24V). One output is selectable as a network controllable dry relay output. Each output may also be individually enabled/disabled through a browser interface and the voltage and current of each output may be monitored via network or internet, and trigger points may be set up on each output to generate an alert when that output is outside of selected parameters.
Features:
- Comprehensive output zone control
- Provides installer selectable output voltage, when used in a dual voltage system
- Visual voltage verification – output LED changes color based on voltage setting (12V/green, 24V/blue)
- Dual voltage buss and prewired cables connect the M8 to the power supply or additional accessory modules
- Fiberglass PCB for improved environmental performance, high efficiency operation
- RoHS compliant
Specifications:
- Input Voltage: 12 and/or 24 VDC
- Input Current: 20 Amps max
- Output Voltage: 12 / 24 VDC
- Current / Output: 3A (fused), 2.5A (pwr ltd)
- Current Measurement Range: 0 – 3.0 Amps
- Voltage Measurement Range: 0 – 30 Volts
- Lock Outputs: 8
- Access Control Inputs: 8
- Fire Alarm Interface: Per output
Attributes
Alternate Codes: M8P-BOXED, M8PBOXED
Category: Access Control, Alarm Power Supplies, Alarms & Intercom, Burglar Alarms, CCTV Products, Power Supplies, Wire & Power Supplies
