Description
Aiphone IX-MV7-HB-L IX Master Station
Aiphone IX-MV7-HB-L IX MASTER STATION offers a sophisticated blend of communication and security features designed for commercial environments. This SIP-compatible IP video master station is equipped with a 7″ touchscreen and a privacy handset, ensuring user-friendly operation and enhanced privacy. With T-Coil hearing aid compatibility, it caters to a wide range of users. Part of the IX Series, this master station facilitates video entry security, internal communication, and emergency announcements, all over a Power over Ethernet (PoE) network. The device supports remote door unlocking, allowing seamless visitor management from offsite locations. It features a high-quality 3-1/2″ color LCD display and a 1/4″ color CMOS camera, offering a view area of 2’2″ x 3’1″ at 20″, ensuring clear visibility. The IX-MV7-HB-L supports various network protocols including IPv4, IPv6, and SIP, while ensuring efficient bandwidth usage with G.711 and H.264 codecs. Installation is straightforward, requiring CAT-5e or CAT-6 wiring. With a durable black finish, this master station not only enhances functionality but also complements modern aesthetics. Weighing just 3.6 lbs, it is easy to mount on surfaces or desks, making it a versatile addition to security systems.
IX MASTER STATION
SIP Compatible IP Video Master Station 7″ Touchscreen and Privacy Handset with T-Coil Hearing Aid Compatibility, Black Finish
The IX Series is a network-based communication and security system featuring video entry security, internal communication, emergency stations, and paging.
Features video entry security, internal communication, and emergency stations.
All units and apps in the systems can unlock doors remotely on a network, assist onsite visitors from an offsite location, broadcast emergency announcements, and communicate using a PoE network.
- Power Source:Power Over Ethernet (802.3af)
- Network Interface:10 BASE‑T / 100 BASE‑TX Ethernet (RJ-45)
- Network Protocols:IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP,
- RTP, RTCP, IGMP, MLD, SMTP, DHCP, NTP, DNS
- Bandwidth Usage:G.711: 64Kbps x 2 per call,;64Kbps per station in paging group;H.264: 24Kbps ~ 2,048Kbps
- Communication:Hands‑free (VOX), push‑to‑talk (simplex),or handset (full-duplex)
- Video Display:3‑1/2″ color LCD
- Camera:Type: 1/4″ color CMOS;View Area: 2’2″ vert. x 3’1″ horiz. at 20″
- Video Stream:ONVIF Profile S
- Door Release:Programmable Form C dry contact, 24V AC/ DC,;500mA – use EL‑12S (use RY‑24L for largercontact rating, which requires 24V DC powersupply) or use RY-IP44 with 4 multipurpose relays
- Wire Type:CAT‑5e or CAT‑6
- Distance:Door Station or RA Station to Network Node: 330′,Master Station to Network Node: 330′
Attributes
Commercial Residential: Commercial
Communication: Voice and Video
Country of origin: Thailand
Display Size: 7″
Finish: Black
Finish Family: Black
Installation: Commercial
Operating Voltage: PoE
Origin: Thailand
Pack Height: 3.25″
Pack Length: 9.75″
Pack Qty: 1
Pack Volume: 396.09 in³
Pack Width: 12.5″
Series: IX IP Video Intercom System
Ship Weight: 3.6 lbs.
Station Mount: Surface Desk
Station Type: Handset
Subtype: Master & Submaster Stations
Type: Intercoms
Unit of Measure: Each
Wire Required: CAT-5E or CAT-6
Resources
- Campus-Wide Safety Brochure
- Emergency and Assistance Intercoms Brochure
- IX Series Brochure – IP Addressable Intercoms and Emergency Stations
- IX Series Components & Accessories
- IX-1AS, IX-10AS LE/NE Sub Station Adaptor for IX Series
- IX-DF-2RA Specifications
- IX-DF-2RA, IX-SS-2RA Instructions
- IX-DF-2RA-FR Instructions
- IX-DF-2RA-FR Specifications
- IX-PA Network Paging Adapter Installation
- IX-SS-RA-FR Instructions
- IX-SS-RA-FR Specifications
- Modular Towers Specifications
- Tower Design Guide
