Arrow Lock BM19 NH 26D IC7 Dormitory Mortise Lock
Arrow Lock BM19 NH 26D IC7 Mortise Lock – Dormitory offers robust security and exceptional performance tailored for dormitory and exit applications. This heavy-duty mortise lock features a satin chrome finish, ensuring both durability and aesthetic appeal. Designed for commercial, institutional, and industrial settings, it meets the stringent performance requirements of ANSI Grade 1. Crafted from heavy gauge steel with a zinc dichromate finish, the lock case is resistant to corrosion and can be re-handed without disassembly, adding convenience for installers. The lock accommodates standard door thicknesses of 1-3/4 inches and comes with a backset of 2-3/4 inches. Key features include a stainless steel latchbolt with an anti-friction insert and a one-piece stainless steel deadbolt, enhancing security. The lock offers master keying options and is compatible with an interchangeable core system, making it versatile for various key control needs. The Arrow BM19 NH 26D is designed to withstand heavy use in high-traffic environments like schools and hospitals, providing peace of mind with a five-year limited warranty. With easy installation and maintenance, this lock is an excellent choice for anyone seeking reliable door security solutions.
Mortise Lock – Dormitory
Dormitory, Exit Mortise Lock, N Lever, H Escutcheon, SFIC Prep Less Core, Satin Chrome
Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.
The BM Series are engineered for strength and performance, and precisely manufactured to exact standards.
Arrow BM Series Lever Mortise Locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required.
- Handing:Handed; field reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness:1-3/4″ (4mm) standard. Optional door thickness available; consult factory.
- Backset:2-3/4″ (70mm).
- Lockcase:Heavy gauge steel, with zinc dichromate finish for corrosion resistance. 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm).
- Armored Front:Heavy gauge steel, 8″ (203 mm) x 1-1/4″ (32mm) x 3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm).
- Faceplate:Wrought brass or bronze, attached by machine screws to lockcase front.
- Latchbolt:Stainless steel, 2 piece mechanical with anti-friction insert. 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Auxiliary Latchbolt:9/16″ (14mm) effective throw and 3/8″ (10mm) effective auxiliary latch deadlocking.
- Deadbolt:One-piece stainless steel, 19/32″ (15mm) x 1 1/4″ (32mm) x 1″ (25mm) throw.
- Hub:Lever: nickel steel, 5/16″ (8mm).
- Spacing:Center to center, hub to cylinder: 3-5/8″ (92mm).
- Center to center, hub to turnpiece: 2-7/16″ (62 mm).
- Strike:Wrought brass or bronze, ANSI straight lip standard, 4-7/8″ (124mm) x 1-1/4″ (32mm) 1-1/8″ (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available.
- Keys:Two nickel silver standard.
- Keying Features Available:
- Master keying
- Construction master keying
- Visual key control
- Concealed key control
- High security cylinder
- Interchangeable core (IC) – Pointe, Pointe Flex
- Warranty:Five-year limited.
Attributes
Ansi Function: F13 – Dormitory
Application: Complete Lock
Base Material: Brass or Bronze
Bolt Projection: 3/4″
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-3/4″
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 19-Dormitory/Exit
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: N – Lever
Limited Warranty: 5 Years
Lock Face Size: 8″ x 1-1/4″
Pack Height: 4.5″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 239.34 in³
Pack Width: 5.75″
Product Height: 8″
Product Length: 2.88″
Product Width: 2.25″
Roseescutcheon Design: H – Escutcheon
Screws: Combination
Series: BM Series Mortise Locks
Ship Weight: 6 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 460
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- AM Series / BM Series Cut Sheet
- AM/BM Series Mortise Lock Catalog
- BM Series Mortise Locks Cut Sheet
