Description
Arrow Lock BM22 VL 26D IC7 Office Mortise Lock
Arrow Lock BM22 VL 26D IC7 Mortise Lock is expertly designed for office environments, providing robust security and reliability. The lock features a V lever and L rose, offering a stylish yet functional aesthetic, all while being prepared for a SFIC core. Crafted from heavy gauge steel with a zinc dichromate finish, this mortise lock is resistant to corrosion, ensuring longevity even in demanding settings like schools and hospitals. This lock is engineered for heavy-duty use and can be easily re-handed without disassembling the lock case, making it a convenient choice for various door configurations. With a standard door thickness of 1-3/4″ and a backset of 2-3/4″, it is versatile enough to meet diverse application needs. The Arrow BM22 includes a stainless steel latchbolt with an anti-friction insert, enhancing durability and ease of use. Its one-piece stainless steel deadbolt provides added security, with a throw of 1″ for optimal protection. The lock also supports various keying options including master keying and concealed key control for added flexibility. With a five-year limited warranty, the Arrow Lock BM22 VL is an excellent investment for those seeking a dependable, high-performance mortise lock that meets ANSI Grade 1 standards.
Mortise Lock – Office
Office Mortise Lock, V Lever, L Rose, SFIC Prep Less Core, Satin Chrome
Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.
The BM Series are engineered for strength and performance, and precisely manufactured to exact standards.
Arrow BM Series Lever Mortise Locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required.
- Handing:Handed; field reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness:1-3/4″ (4mm) standard. Optional door thickness available; consult factory.
- Backset:2-3/4″ (70mm).
- Lockcase:Heavy gauge steel, with zinc dichromate finish for corrosion resistance. 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm).
- Armored Front:Heavy gauge steel, 8″ (203 mm) x 1-1/4″ (32mm) x 3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm).
- Faceplate:Wrought brass or bronze, attached by machine screws to lockcase front.
- Latchbolt:Stainless steel, 2 piece mechanical with anti-friction insert. 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Auxiliary Latchbolt:9/16″ (14mm) effective throw and 3/8″ (10mm) effective auxiliary latch deadlocking.
- Deadbolt:One-piece stainless steel, 19/32″ (15mm) x 1 1/4″ (32mm) x 1″ (25mm) throw.
- Hub:Lever: nickel steel, 5/16″ (8mm).
- Spacing:Center to center, hub to cylinder: 3-5/8″ (92mm).
- Center to center, hub to turnpiece: 2-7/16″ (62 mm).
- Strike:Wrought brass or bronze, ANSI straight lip standard, 4-7/8″ (124mm) x 1-1/4″ (32mm) 1-1/8″ (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available.
- Keys:Two nickel silver standard.
- Keying Features Available:
- Master keying
- Construction master keying
- Visual key control
- Concealed key control
- High security cylinder
- Interchangeable core (IC) – Pointe, Pointe Flex
- Warranty:Five-year limited.
Attributes
Ansi Function: F04 – Entry/Office
Application: Complete Lock
Base Material: Brass or Bronze
Bolt Projection: 3/4″
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-3/4″
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 22-Office
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: V – Lever
Limited Warranty: 5 Years
Lock Face Size: 8″ x 1-1/4″
Pack Height: 4.5″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 239.34 in³
Pack Width: 5.75″
Product Height: 8″
Product Length: 2.88″
Product Width: 2.25″
Roseescutcheon Design: L – Rose
Screws: Combination
Series: BM Series Mortise Locks
Ship Weight: 6 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 463
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- AM Series / BM Series Cut Sheet
- AM/BM Series Mortise Lock Catalog
- BM Series Mortise Locks Cut Sheet
