Description
Arrow Lock BM23 JL 26D Vestibule Mortise Lock
Arrow Lock BM23 JL 26D Mortise Lock is a robust vestibule lock designed for high-traffic environments such as schools, hospitals, and commercial buildings. Engineered for superior strength and performance, this lock meets the rigorous demands of ANSI Grade 1 standards, ensuring exceptional durability and low maintenance. The heavy gauge steel lock case features a zinc dichromate finish, providing excellent corrosion resistance, and can be easily re-handed without disassembly. This mortise lock is compatible with standard door thicknesses of 1-3/4″ and comes with a backset of 2-3/4″. The lock’s stainless steel latchbolt includes an anti-friction insert, contributing to its longevity and smooth operation. Additionally, the one-piece stainless steel deadbolt offers enhanced security with a 1″ throw, while the auxiliary latchbolt provides effective deadlocking. The Arrow BM23 is equipped with a J Lever design and an L Rose, finished in a sleek satin chrome. It includes two nickel silver keys and offers various keying options such as master keying and high security cylinders. With a five-year limited warranty, this lock is a reliable choice for those seeking a secure and stylish locking solution. Experience peace of mind with the dependable performance of the Arrow Lock BM23 JL 26D Mortise Lock.
Mortise lock – Vestibule
Vestibule Mortise Lock, J Lever, L Rose, Satin Chrome
Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.
The BM Series are engineered for strength and performance, and precisely manufactured to exact standards.
Arrow BM Series Lever Mortise Locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required.
- Handing:Handed; field reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness:1-3/4″ (4mm) standard. Optional door thickness available; consult factory.
- Backset:2-3/4″ (70mm).
- Lockcase:Heavy gauge steel, with zinc dichromate finish for corrosion resistance. 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm).
- Armored Front:Heavy gauge steel, 8″ (203 mm) x 1-1/4″ (32mm) x 3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm).
- Faceplate:Wrought brass or bronze, attached by machine screws to lockcase front.
- Latchbolt:Stainless steel, 2 piece mechanical with anti-friction insert. 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Auxiliary Latchbolt:9/16″ (14mm) effective throw and 3/8″ (10mm) effective auxiliary latch deadlocking.
- Deadbolt:One-piece stainless steel, 19/32″ (15mm) x 1 1/4″ (32mm) x 1″ (25mm) throw.
- Hub:Lever: nickel steel, 5/16″ (8mm).
- Spacing:Center to center, hub to cylinder: 3-5/8″ (92mm).
- Center to center, hub to turnpiece: 2-7/16″ (62 mm).
- Strike:Wrought brass or bronze, ANSI straight lip standard, 4-7/8″ (124mm) x 1-1/4″ (32mm) 1-1/8″ (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available.
- Keys:Two nickel silver standard.
- Keying Features Available:
- Master keying
- Construction master keying
- Visual key control
- Concealed key control
- High security cylinder
- Interchangeable core (IC) – Pointe, Pointe Flex
- Warranty:Five-year limited.
Attributes
Application: Complete Lock
Base Material: Brass or Bronze
Bolt Projection: 3/4″
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4″
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 23-Vestibule
Grade: Grade 1
Handing: Field Reversible
Keying: Keyed Different
Keys: Cut
Leverknob Design: J – Lever
Limited Warranty: 5 Years
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Pack Height: 4.5″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 239.34 in³
Pack Width: 5.75″
Pins: 6
Product Height: 8″
Product Length: 2.88″
Product Width: 2.25″
Roseescutcheon Design: L – Rose
Screws: Combination
Series: BM Series Mortise Locks
Ship Weight: 6 lbs.
Std Keyway: A
Std Strike Height: 4-7/8″
Std Strike Number: 463
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- AM Series / BM Series Cut Sheet
- AM/BM Series Mortise Lock Catalog
- BM Series Mortise Locks Cut Sheet
