Description
Camden CM-1130 Key Switch Control Instructions
Camden CM-1130 Key Switch Control offers a robust solution for managing access control in commercial settings. This single gang key switch operates on a versatile 12/24 VAC/DC voltage, providing flexibility for a variety of installation needs. Featuring a maintained SPDT switch with both normally open (N/O) and normally closed (N/C) options, the CM-1130 ensures reliable operation and control over connected devices. Crafted from 1/4-inch thick aluminum, the key switch presents a durable, one-piece die-cast construction that stands up to rigorous use. The sleek aluminum finish not only enhances its aesthetic appeal but also ensures longevity, making it a practical choice for high-traffic environments. Designed to fit standard mortise cylinders, it seamlessly integrates into existing systems. With a compact design, the CM-1130 measures 4.5 inches in height, 2.75 inches in width, and 1.5 inches in depth, making it easy to install in various locations. Camden stands behind their product with a three-year limited warranty, providing peace of mind. Ideal for commercial applications, the CM-1130 Key Switch Control is a reliable addition to any access control system, ensuring security and ease of use.
Key Switch Control
Single Gang Key Switch, 12/24 VAC/DC, SPDT Switch, N/O and N/C, Maintained, Aluminum Finish
Camden Door Controls, CM-1100 and CM-2000 Series flush mount key switches meet the stringent demands of key switch controls. They are designed for use with standard 1âÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìââÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂâìÃÂìèâÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂÃÂìù, 1 1/8âÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìââÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂâìÃÂìèâÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂÃÂìù, or 1 1/4âÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìââÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂâìÃÂìèâÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂÃÂìù mortise cylinders. Fabricated from 1/4âÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìÃÂâÂÂÃÂìââÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂâìÃÂìèâÂÂÃÂìÃÂâÂÂâìÃÂìöâÂÂÃÂìÃÂâÂÂÃÂìù thick aluminum, into a one piece die cast construction, with unique Camden Manufacturing features.
Attributes
Base Series: Camden Key Switches
Box Depth Fraction: 2-1/2″
Box Height Fraction: 5-3/4″
Box Width Fraction: 3-1/4″
Commercial Residential: Commercial
Country of origin: Canada
Finish: Aluminum
Finish Family: Matte Silver
Fire Rated: No
Fire Rating: No
Installation: Commercial
Limited Warranty: 3 Years
Mounting Plate Size: 1 Gang
Operating Voltage: 12/24V AC/DC
Origin: Canada
Pack Height: 5.75″
Pack Length: 2.5″
Pack Qty: 1
Pack Volume: 46.72 in³
Pack Width: 3.25″
Product Height: 4.5″
Product Length: 1.5″
Product Width: 2.75″
Relay Action: Maintained (AA)
Relay Type: SPDT
Series: Camden Keyswitches, Pushbuttons and Pull Stations
Ship Weight: 0.49 lbs.
Subtype: Keyswitches
Type: Sensors, Switches, Relays, Timers
Unit of Measure: Each
Upc: 6.70E+11
Upc Code: 6.70E+11
