Description
Schlage B563P606 Grade 2 Classroom Deadbolt with C Keyway with 12287 Latch and 10094 Strike Satin Brass Finish
Schlage Commercial B563P606 Grade 2 Classroom Deadbolt with C Keyway with 12287 Latch and 10094 Strike Satin Brass Finish
- Classroom Deadbolt – Deadbolt Thrown or Retracted by Key Outside, Inside Turn Unit Will Retract Bolt Only
- ANSI Certified A156.36
- 1-3/8″ to 1-7/8″ Door Range
- UL Listed for 3 Hour Fire Door
- Commercial Grade 2
Attributes
Manufacturer surcharge: 4.5%
Ansi: A156.36, 2010
Ansi Function: E0172 – Classroom Deadbolt
Baa Qualified: Yes
Backset: Adjustable Backset
Bolt Projection: 1″
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: 6-Pin Cylinder
Door Thickness: 1-3/8″ – 1-7/8″
Dust Box: Metal
Finish: Satin Brass
Finish : Satin Brass
Finish Family: Matte Brass
Function: Classroom Deadbolt
Grade: Grade 2
Installation: Commercial
Keying: Keyed 5
Keys: 5-pin, C section
Limited Warranty: 3 Years
Lock Face Size: 1″ x 2-1/4″
Mechanical Option: Keyed Outside x Classroom Thumbturn Inside
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Product Height: 4.13″
Product Width: 2.54″
Series: B500 Series
Std Latch Backset Dim: Adjustable for 2-3/8″ or 2-3/4″
Std Latch Number: 12-288
Std Latch Type: Square Corner
Std Strike Height: 2-3/4″
Std Strike Number: 10-094
Std Strike Type: Square Corner
Std Strike Width: 1-1/8″
Strike: Square 2-3/4″ Strike
Subtype: Deadbolts
Type: Mechanical Commercial Locksets
Unit of Measure: Each
Resources
- B500 Series Data Sheet
- B500 Series Deadbolts Cut Sheet
- B500 Series Installation Instructions
- B560, 61, 62, 63 Template
- B571 Template
- Schlage B Series Indicator Pricing Addendum
- Schlage B Series Service Manual
- Von Duprin Finishes Chart
