Description
Corbin Russwin ML2003 PSM 630 LC Classroom Mortise Lock
Corbin Russwin ML2003 PSM 630 LC Classroom Mortise Lock offers a robust and reliable solution for high-traffic environments. As a Grade 1 Classroom Mortise Lock, it is meticulously designed to withstand the demands of commercial, institutional, and industrial applications. The lock features a satin stainless steel finish that not only enhances its aesthetic appeal but also contributes to its durability. Constructed from heavy-gauge steel, the lockbody includes a patented quick reversible latchbolt and a solid 1″ stainless steel deadbolt, ensuring maximum security. The ML2003 is field-reversible, allowing for easy handing adjustments without disassembling the lock case. Its standard door thickness accommodates 1-3/4″ doors, with options available for other thicknesses. The lock’s M Escutcheon design, combined with a Princeton lever, provides a modern touch, and its versatile functionality makes it suitable for offices, schools, hospitals, and hotels. Additionally, it meets federal standards FF-H-106C and is UL listed, ensuring compliance with safety regulations. With a 10-year limited warranty and an environmental product declaration, the Corbin Russwin ML2003 not only prioritizes security but also emphasizes sustainability and reliability, making it the ideal choice for your door hardware needs.
Classroom Mortise Lock
Grade 1 Classroom Mortise Lock, Princeton Lever, M Escutcheon, Less Cylinder, Satin Stainless Steel Finish, Field Reversible
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1″ stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Ansi: A156.13, Series 1000
Baa Qualified: Yes
Base Series: ML2000
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Less Cylinder
Door Thickness: 1-3/4″
Finish: 630/US32D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 03-Classroom
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Leverknob Design: PS – Princeton Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Origin: USA
Pack Height: 4.5″
Pack Length: 10″
Pack Qty: 1
Pack Width: 7.5″
Roseescutcheon Design: M Escutcheon
Series: ML2000 Series Mortise Locks
Ship Weight: 4 lbs.
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
