Description
Yale LBDY8812-2FL 626 Classroom Security Mortise Body
Yale LBDY8812-2FL 626 Classroom Security Mort Body delivers exceptional strength and durability, tailored specifically for commercial applications. This Grade 1 lever mortise lock features a double cylinder design with a robust deadbolt function, ensuring enhanced security where it matters most. The satin chrome finish not only adds a touch of elegance but also offers resistance against wear and tear. Designed for ease of installation, the LBDY8812-2FL provides quick lever handing and a field-reversible latchbolt, accommodating various door configurations. With a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim, this lock meets the stringent ANSI/BHMA Grade 1 certification, ensuring long-lasting performance. The lock mechanism includes a stainless steel construction, with a 3/4″ throw latchbolt and compatibility with standard door thicknesses of 1-3/4″, extending up to 3-1/4″ upon request. It also features a curved lip strike, with customizable options available. The lock comes with a 6-pin, brass cylinder and is available in 17 finishes, allowing for flexibility in design. Backed by a 10-year mechanical warranty, the Yale LBDY8812-2FL is the ideal choice for those seeking a reliable and secure solution for classroom environments and beyond.
Classroom Security Mort Body
Grade 1 Lever Mortise Lock Body, Double Cylinder Classroom Security with Deadbolt Function, Satin Chrome Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Ansi Function: F34 – Classroom Security with Deadbolt and Auxiliary Latch
Commercial Residential: Commercial
Cylinder Type: Less Cylinder
Finish: 626/US26D
Finish Family: Matte Silver
Function: 12-2-Intruder Deadbolt Lock
Grade: Grade 1
Installation: Commercial
Pack Qty: 1
Series: Yale 8800 Series Mortise Locks
Subtype: Lock Bodies
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 2023 Yale Commercial Price Book (effective 4.17.2023)
- 8800 Series Handing Instructions
- 8800 Series Mortise Lock – Environmental Product Declaration (EPD)
- 8800 Series Mortise Lock Installation Instructions
- 8800 Series Parts Manual
- 8800 Series Upgrade Solutions Sell Sheet
- 8800-ITS Mortise Lockset Installation Instructions
- Yale 8800 Series Mortise Lock Catalog
- Yale 8800 Series Mortise Lock with Status Indicators Sell Sheet
- Yale 8800 Series Mortise Locks Cut Sheet
- Yale Commercial Finishes Chart
- Yale Competitor Indicator Kits Catalog
- Yale Reflections Catalog
