Description
Adams Rite 8622A-36B Concealed Vertical Rod Device
Adams Rite 8622A-36B Concealed Vertical Rod Device offers a sophisticated solution for securing narrow stile aluminum doors. This 36-inch exit device features a battery-operated alarm, ensuring enhanced security while maintaining a sleek, unobtrusive design that blends seamlessly with modern architecture. Ideal for aluminum applications, its dark bronze anodized finish not only provides durability but also adds an elegant touch. The device employs a patented “Starwheel” bolt mechanism, which interlocks the door to the frame upon closure. This innovative feature includes an interlocking noseguard and deadlocking slide, ensuring reliable locking performance. Installation is straightforward, and the device is non-handed, allowing for versatile application on various door setups. Capable of accommodating standard door heights of up to 8 feet and thicknesses ranging from 1-3/4 inches to 2-1/4 inches, this exit device provides flexibility for many commercial environments. The pushbar is adjustable from 30 inches to 44 inches, with options for electric dogging available for specific models. Backed by a five-year limited warranty, the Adams Rite 8622A-36B is a robust choice for professionals seeking security and functionality without compromising aesthetics.
Concealed Vertical Rod Device
Narrow Stile Concealed Vertical Rod Exit Device, Battery Operated Alarm, For Aluminum Applications, 36 In., Dark Bronze Anodized Aluminum
CVR Exit Device, Narrow Stile Aluminum Door, 36″, Battery Operated Alarm, Dark Bronze
Clean, unobtrusive design. Easy to install.
Patented “Starwheel” bolt interlocks door to frame, which is a unique feature for exit devices. The “Starwheel” bolt comes into play when the door closes. The interlocking noseguard and starwheel bolt close around the strike. The deadlocking slide springs over, locking the starwheel bolt to the strike. When the pushbar is depressed, the deadlocking slide moves back, allowing the door to unlock from the strike.
- Materials:Pushbar made of extruded aluminum, clad or anodized in a variety of finishes.
- Handing:Device is non-handed. Lever Entry Trim is field reversible.
- PushbarLength: Standard sizes: dimensioned for 30”, 36”, 42”, and 48” openings. Standard width bars can be field cut to the next smallest opening width.
- Bar Height:Standard model adjusts from 30” to 44”.
- Door Height: Standard model fits up to 8 ft door, with bar height at 40”– 44”. For doors up to 10 ft. Tall Door Kit available separately: 8055 Tall Door Kit for 8100 or 3055 Tall Door Kit for 3100.
- Door Thickness:Suits 1-3/4” standard, up to 2-1/4”.
- Stile Width:3100 – Minimum 3-3/4”. Door construction may require additional stile width to meet fire ratings and provide adequate strength. 8100 – Minimum 3-3/4”.
- Projection: 2-15/16” when fully projected, 1-15/16”when dogged.
- Dogging: Standard dogging with hex key or optional cylinder dogging for 8100 Series only. Electric dogging also available for 3100 and 8100 Series.
- Fasteners:Standard self-tapping screws. Optional Sex Bolt Kits 26-0584 (two required per device). Specify finish.
- Cylinders(available separately): SeeCYLINDERSfor cylinder make, thumbturn and trim ring information.
- Cylinder x Fixed Pull:(ANSI/BHMA Function 03): Accepts any standard Rim cylinder.
- 3080 Entry Trim(ANSI/BHMA Functions 08, 09): Accepts any standard diameter Mortise cylinder with MS cam. Accommodates cylinder lengths from 1” to 1-1/4”. (Available separately)
- Warranty:Five year limited.
Attributes
Commercial Residential: Commercial
Device Length: 36″
Device Type: Concealed Vertical Rod
Door Height: 8 Ft.
Door Thickness: 1-3/4 In. – 2-1/4 In.
Electric Options: Battery Powered Alarm Kit
Finish: 313
Finish Family: Dark Bronze
Fire Rated: No
Handing: Non-Handed
Includes Trim: No
Installation: Commercial
Mechanical Function: Universal
Minimum Stile Size: 2 In.
Pack Qty: 1
Pbs Options: 10,399,022,157,406,900
Physical Appearance: Narrow Stile Pushpad
Series: 8000 Series Exit Devices
Subtype: Concealed Vertical Rod Exit Devices
Type: Exit Devices
Unit of Measure: Each
