Description
Corbin Russwin ED4800 613E Concealed Vertical Rod Device
Corbin Russwin ED4800 613E Concealed Vertical Rod Device is engineered for optimal performance in high-use and high-abuse environments. This narrow stile exit device, measuring 36 inches and finished in a dark oxidized bronze, is designed to seamlessly integrate with aluminum and metal doors while meeting ANSI Grade 1 requirements. The ED4800 features an easy-to-use pushpad that ensures quick egress and ADA compliance, making it an ideal choice for commercial settings. Its low projection design adheres to barrier-free code compliance, and the heavy-duty construction guarantees durability and reliability over time. With closed sides and no projecting parts, users can exit freely without obstruction. This device accommodates various function trims, providing versatility for different applications, while the through-bolted trims enhance strength and security. The one-point dogging feature simplifies operation, further supported by quiet functionality. Additionally, the ED4800 is compatible with a range of Corbin Russwin trims, allowing for tailored aesthetics in new constructions or renovations. With a limited warranty of 5 years and compliance with UL/cUL safety requirements, the Corbin Russwin ED4800 is a robust solution for any commercial door hardware need.
Concealed Vertical Rod Device
Narrow Stile Concealed Vertical Rod Exit Device, 36″, Dark Oxidized Bronze
Available in Rim, Surface Vertical Rod, Concealed Vertical Rod and electrified, the ED4000 Series meets all your aluminum and metal door needs. Features Meets ANSI Grade 1 requirements Easy-to-use pushpad for quick egress and ADA compliance Low projection for barrier-free code compliance Heavy-duty construction Quiet operation Closed on all sides – no projecting parts to inhibit egress Devices accommodate various function trims for flexibility Through-bolted trims for strength, security, durability, smooth operation and easy installation Wide range of designs and finishes to match other Corbin Russwin products One-point dogging Devices satisfy UL/cUL safety requirements
Designed for applications on narrow stile full glass, aluminum and metal doors in high-use and high-abuse situations.
ED4000 Series devices can be teamed with a variety of Corbin Russwin trims to provide desired functions, styles and finishes in new construction and renovations.
- Meets ANSI Grade 1 requirements
- Easy-to-use pushpad for quick egress and ADA compliance
- Low projection for barrier-free code compliance
- Heavy-duty construction
- Quiet operation
- Closed on all sides – no projecting parts to inhibit egress
- Devices accommodate various function trims for flexibility
- Through-bolted trims for strength, security, durability, smooth operation and easy installation
- Wide range of designs and finishes to match other Corbin Russwin products
- One-point dogging
- Devices satisfy UL/cUL safety requirements
Attributes
Base Material: Bronze
Commercial Residential: Commercial
Device Length: 36″
Device Type: Concealed Vertical Rod
Door Height: 96 in
Door Material: Aluminum
Door Thickness: 1 3/4 In.
Door Width: 30 In. – 36 In.
Finish: 613E/US10BE
Finish Family: Dark Bronze
Fire Rated: No
Grade: Grade 1
Handing: Reversible
Includes Cylinders: No
Includes Trim: No
Installation: Commercial
Limited Warranty: 5 Years
Mechanical Function: Exit Only, Accepts Trim
Minimum Stile Size: 2 In.
Pack Height: 5.75″
Pack Length: 39.75″
Pack Qty: 1
Pack Volume: 2342.77 in³
Pack Width: 10.25″
Physical Appearance: Narrow Stile Pushpad
Reversible: Yes
Series: ED4000 Series Narrow Stile Pushpad Exit Devices
Ship Weight: 16.1 lbs.
Strike Bottom: 650F57-8
Subtype: Concealed Vertical Rod Exit Devices
Top Strike: 650F54-8
Type: Exit Devices
Unit of Measure: Each
Resources
- 2 – ED4000/5000 x M94 x 2 – 6900 Powermatic x 2 Actuators
- 781N General Wiring Information
- 782 Power Controller
- 810, 850, 855, 859 Series Trim
- DEED Delayed egress wired to release both exits when one goes into alarm
- Delayed Egress Exit – All Functions
- Delayed Egress x DK11 x BPS
- Delayed Egress x MKA2 x BPS
- ED 4000/5000 M94 x DK11 x BPS 24 1 Pair Doors
- ED4000 Series Catalog
- ED4000 Series Narrow Stile Pushpad Exit Devices Cut Sheet
- ED4000, ED5000 with M61 Alarm Option and ED40AK, ED50AK Alarm Retrofit Kit Installation Instructions
- ED4000/5000 x M92 to Shunt Actuators x 6900 Powermatic x 2 Wall Plates Pair Doors
- ED4000/5000 x M92 to Shunt Actuators x 6900 Powermatic x 2 Wall Plates Sgl Doors
- ED4000/5000 x M94 x 6900 Powermatic x 2 Wall Plates
- ED4000/5000 x M94 x 6900 Powermatic x 2 Wall Plates By MKA Key Switch to Disable Exterior Actuator
- ED4000/5000 x M94 x 6900 Powermatic x DK 11 x 1 Wall Plates Interior
- ED4000/5000 x M94 x 6900 Powermatic x Mag x DK 11 x 1 Wall Plates Interior
- ED4000/5000 x M94 x DK11 x BPS 24 1
- ED4000/ED5000 – Exits with Electric Latch Pullback and-or Monitors Installation Instructions
- ED4000/ED5000 Delayed Egress Exit Device Installation Instructions
- ED4000/ED5000 Series Parts Manual
- ED4200, ED4200M, ED4200MA, ED4200S, ED4200SM, ED4200SMA Series Rim & SecureBolt
- ED4400, ED4400M and ED4400MA Series Surface Vertical Rod Exit Devices
- ED4800, ED4800M, ED4800MA Series Concealed Vertical Rod Exit Devices
- Pair ED4000/5000 x M94 x 2- 6900 Powermatic x 2 Wall Plates By MKA Key Switch to Disable Exterior Ac
