Corbin Russwin ML2067 CSA 626 M31 Apartment Mortise Lock Trim Instructions
Corbin Russwin ML2067 CSA 626 M31 Apartment Mortise Lock Trim is a robust solution tailored for high-traffic environments such as apartments, dormitories, offices, and educational institutions. This Grade 1 mortise lock is constructed from heavy-gauge steel, ensuring durability and reliability in demanding settings. Featuring a patented quick reversible latchbolt and a 1″ stainless steel deadbolt, it provides enhanced security without compromising on ease of use. The trim pack includes the stylish CS Citation Lever and an A Rose design, finished in a sleek Satin Chrome (626/US26D). Designed for standard door thicknesses of 1-3/4″, it accommodates a backset of 2-3/4″. This lockset is field-reversible, allowing for easy handing adjustments without disassembly, making it versatile for various installation needs.With a 10-year limited warranty, the Corbin Russwin ML2067 offers peace of mind in residential and commercial applications alike. It meets federal standards (FF-H-106C) and is ADA compliant, ensuring accessibility for all users. Additionally, its fire rating of 3 hours provides added safety for multi-family residences. The ML2000 series is the ideal choice for those seeking a reliable, high-performance locking solution.
Apartment Mortise Lock Trim
Apartment or Dormitory Mortise Trim Pack, CS Lever, A Rose, Satin Chrome
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1″ stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Accessible: Yes
Ada Compliance: Yes
Ansi Function: F20 – Entry/Office
Application: Trim Pack Only
Baa Qualified: Yes
Base Material: Brass or Bronze
Country of origin: USA
Door Thickness: 1-3/4″
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 67-Apartment or Dormitory
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: CS – Citation Lever
Limited Warranty: 10 Years
Origin: USA
Pack Qty: 1
Roseescutcheon Design: A Rose
Series: ML2000 Series Mortise Locks
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
