Description
Corbin Russwin CLX33903 AZD 626 M08 M92 Grade 1 Electric Fail Safe Lock, 12/24V
Corbin Russwin CLX33903 AZD 626 M08 M92 Grade 1 Elec, Fail Safe 12/24V offers a perfect blend of security and style, designed for high-traffic environments. This Grade 1 electromechanical cylindrical lock features an Armstrong Lever and a D Rose escutcheon, ensuring a sophisticated appearance without compromising on strength. With a fail-safe function and compatibility with 12/24V power supply, this lock is ideal for various commercial applications. Constructed with premium materials, the CLX3300 Series guarantees durability and reliability, making it suitable for both new construction and retrofit projects. The lock’s non-handed design accommodates doors with a thickness of 1-3/4″ to 2″ and includes a standard 2-3/4″ backset for easy installation. The satin chrome finish not only adds a contemporary touch but also provides resistance against wear and tear. This lock supports all cylinder formats, including SFIC prep less core, and is equipped with a Request to Exit switch for added functionality. Fire rated for up to 3 hours, the CLX33903 is UL listed and meets rigorous safety standards, ensuring peace of mind in any setting. Backed by a 10-year limited warranty, this lock stands as a reliable choice for securing your premises.
Grade 1 Elec, Fail Safe 12/24V
Grade 1 Electromechanical Cylindrical Lock, Fail Safe, Armstrong Lever, D Rose, SFIC Prep Less Core, 2-3/4″ Backset, Request to Exit, Satin Chrome Finish, Non-Handed
The CLX3300 Series ANSI/BHMA Grade 1 cylindrical lock is designedto secure high-traffic spaces where aesthetics are important. Manufactured of the highest-quality materials to provide durability, strength, and reliability, it is also available in all industry-standard finishes and a variety of decorative levers, so you’ll never have to sacrifice style for strength. It supports all cylinder formats – from fixed to interchangeable cores, and is the ideal choice for new construction and retrofit projects.
Electrified Grade 1 locks with the strength to secure high-traffic openings with design options to complement any decor.
Attributes
Amp Draw: 250 mA @ 12VAC/VDC or 150mA @ 24VAC/VDC
Ansi: F75
Bolt Projection: 1/2″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-3/4″ to 2″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 903-Electromechanical (Fail Safe)
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Backset Dim: 2-3/4″
Leverknob Design: AZ – Armstrong Lever
Limited Warranty: 10 Year Limited Warranty
Lock Face Size: 1-1/8″ x 2-1/4″
Operating Voltage: 12 or 24 VAC/DC
Origin: United States
Pack Height: 4.5″
Pack Length: 10″
Pack Qty: 1
Pack Volume: 360 in³
Pack Width: 8″
Pins: 6 or 7
Product Height: 4.5″
Product Length: 10″
Product Width: 8″
Roseescutcheon Design: D Rose
Screws: Wood/Machine Screws
Series: CLX3300 Series Electrified Grade 1 Cylindrical Lever Locks
Ship Weight: 7 lbs.
Std Latch Number: 867F21
Std Latch Type: Deadlatch
Std Strike Height: 4-7/8″
Std Strike Number: SA114
Std Strike Type: ANSI Curved Lip Strike
Std Strike Width: 1-1/4″
Subtype: Electric Cylindrical Lock
Switch Type: Request to Exit
Type: Electric Locks
Ul Listing: ANSI A156.2 (2017), A156.41, Series 4000, Grade 1, UL Listed
Unit of Measure: Each
