Description
Corbin Russwin ML2032 106T 630 CL6 Institution Mortise Lock
Corbin Russwin ML2032 106T 630 CL6 Institution Mortise Lock delivers robust security designed for high-traffic environments. This Grade 1 mortise lock features a heavy-gauge steel lockbody, ensuring durability essential for commercial, institutional, industrial, and government applications. The patented Quick Reversible latchbolt allows for easy re-handing, enabling versatility in installation without disassembling the lock. The ML2032 is equipped with a 1-inch stainless steel deadbolt, providing an extra layer of protection. Its Salvador lever design and T Rose escutcheon blend functionality with a sleek aesthetic, fitting seamlessly into various architectural styles. With a standard door thickness of 1-3/4 inches and a backset of 2-3/4 inches, it is compatible with most door configurations. This lock also meets rigorous federal standards (FF-H-106C) and comes with a 10-year limited warranty, reflecting its reliability. The lock is UL Listed for fire safety, rated for up to 3 hours. With a 6-pin LFIC prep and less core, it accommodates various keying systems. The ML2032 is an ideal choice for offices, schools, hospitals, and hotels, delivering peace of mind through superior locking performance and adaptability.
Institution Mortise Lock
Grade 1 Institution or Utility Mortise Lock, Salvador Lever, T Rose, 6-Pin LFIC Prep, Less Core, Satin Stainless Steel Finish, Field Reversible
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1″ stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Ansi: A156.13, Series 1000
Ansi Function: F30 – Asylum
Baa Qualified: Yes
Base Series: ML2000
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: 6-Pin LFIC Prep, Less Core
Door Thickness: 1-3/4″
Finish: 630/US32D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 32-Institution or Utility
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Leverknob Design: 106 – Salvador Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Origin: USA
Pack Height: 4.5″
Pack Length: 10″
Pack Qty: 1
Pack Width: 7.5″
Pins: 6
Roseescutcheon Design: T Rose
Series: ML2000 Series Mortise Locks
Ship Weight: 4 lbs.
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
Resources
- Assa Abloy Hands-Free and Touchless Solutions Flyer
- Corbin Strikes/Kits Brochure
- ML2000 Inspire Roseless Trim (J) Installation Instructions
- ML2000 Series Mortise Lock – Environmental Product Declaration (EPD)
- ML2000 Series Mortise Locks Cut Sheet
- ML2000VR Vandal Resistant Trim Installation Instructions
- Mortise Lock Occupancy Indicators (With Cylinder) Installation Instructions
- Mortise Lock Occupancy Indicators (Without Cylinder) Installation Instructions
- Video: Changing the Hand on the ML20608
- Video: HPSK Push/Pull Trim Installation
- Video: ML2000 Series Mortise Lock with Sectional Rose Trim Installation
