Description
Corbin Russwin ML2069 DSA 626 RH M31 Institutional Privacy Mortise Trim
Corbin Russwin ML2069 DSA 626 RH M31 Institution Privacy Mort Trim offers robust security and functionality for high-traffic environments such as offices, schools, and hospitals. This Grade 1 mortise lock is engineered for reliability, featuring a heavy-gauge steel lockbody equipped with a patented Quick Reversible latchbolt and a durable 1″ stainless steel deadbolt.The design accommodates standard door thickness of 1-3/4″ and includes a 2-3/4″ backset, ensuring versatility across various installations. Aesthetically pleasing, the trim pack features a DS lever and an A Rose design, finished in elegant satin chrome. With a 10-year warranty, you can trust the longevity and performance of the ML2000 Series. Enhanced security is a priority, as the lock incorporates a two-piece mechanical latchbolt with an anti-friction insert, promoting smooth operation. This model meets FF-H-106C federal specifications and adheres to ADA compliance, ensuring accessibility for all users.Whether you’re upgrading an existing system or outfitting a new build, the Corbin Russwin ML2069 DSA delivers the strength and dependability needed for institutional privacy applications, making it an ideal choice for enhancing both security and user experience.
Institution Privacy Mort Trim
Institutional Privacy Mortise Trim Pack, DS Lever, A Rose, Satin Chrome
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1″ stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Accessible: Yes
Ada Compliance: Yes
Ansi Function: F26 – Institutional Privacy
Application: Trim Pack Only
Baa Qualified: Yes
Base Material: Brass or Bronze
Country of origin: USA
Door Thickness: 1-3/4″
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 69-Institutional Privacy
Grade: Grade 1
Handing: RH
Leverknob Design: DS – Dirke Lever
Limited Warranty: 10 Years
Origin: USA
Pack Qty: 1
Roseescutcheon Design: A Rose
Series: ML2000 Series Mortise Locks
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
