Corbin Russwin ML2030 RWA BSP Privacy Bed/Bath Mortise Lock Instructions
Corbin Russwin ML2030 RWA BSP Privacy Bed/Bath Mortise Lock delivers a reliable locking solution ideal for high-traffic environments such as offices, schools, and hotels. This Grade 1 mortise lock is constructed from heavy-gauge steel, ensuring durability and long-lasting performance. Featuring a patented quick reversible latchbolt and a robust 1-inch stainless steel deadbolt, this lock provides exceptional security without sacrificing ease of use. Designed for privacy applications, the ML2030 is perfect for bedrooms and bathrooms, offering a stylish RW lever design with an A rose in a striking black suede powder coat finish. The lock accommodates standard door thicknesses of 1-3/4 inches, with optional variations available to suit different installations.Installation is straightforward, thanks to its handed design that can be easily reversed without disassembling the lock case. The heavy-duty lockcase measures 5-7/8 inches by 4 inches and is complemented with a 10-year limited warranty, assuring its reliability. It meets FF-H-106C federal specifications and is EPD certified, making it an environmentally conscious choice. With two nickel silver keys included and a bolt projection of 3/4 inches for the latchbolt and 1 inch for the deadbolt, the Corbin Russwin ML2030 RWA is a dependable choice for enhancing the security and functionality of your spaces.
Privacy Bed/Bath Mortise Lock
Privacy, Bedroom or Bathroom Mortise Lock, RW Lever, A Rose, Black Suede Powder Coat
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1 stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Ansi Function: F19 – Privacy/Bed/Bath
Application: Complete Lock
Bolt Projection: 3/4″ Latchbolt, 1″ Deadbolt
Country of origin: USA
Cylinder Type: Mortise Cylinder
Door Thickness: 1-3/4 In.
Finish: BSP
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 30-Privacy Bedroom or Bathroom
Grade: Grade 1
Handing: Field Reversible
Keying: 0 Bitted
Keys: Blank
Leverknob Design: RW – Regis Lever
Limited Warranty: 10 Years
Lock Face Size: 8 In. x 1-1/4 In.
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Roseescutcheon Design: A Rose
Screws: Combination
Series: ML2000 Series Mortise Locks
Std Keyway: L4
Std Strike Height: 4-7/8 In.
Std Strike Number: 236L72018
Std Strike Type: ASA
Std Strike Width: 1-1/4 In.
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
