Description
Detex 1003C LD 630 99 48 48″ Rim Exit Device Instructions
Detex 1003C LD 630 99 48 Rim Exit Device 48 Inch offers a robust solution for panic and fire exit requirements in both commercial and residential settings. This super-heavy-duty exit device is expertly designed for single and double doors, even those with mullions, ensuring maximum security and ease of access.Featuring a patented mounting plate and a strike locator system, the installation process is simplified, allowing for the most accurate fitting available on the market. The device measures 48 inches in length and comes with a night latch trim, providing added functionality without the need for dogging.Crafted from high-quality stainless steel with a satin finish (630/US32D), this exit device not only enhances security but also complements the aesthetic of your doors with its matte silver appearance. Designed specifically for commercial applications, the wide stile pushpad makes it easy to operate, ensuring a swift exit in emergency situations.With the Detex 1003C, you are investing in superior heavy-duty exit hardware that prioritizes safety and efficiency. It ships conveniently via UPS, making it a practical choice for any building professional or knowledgeable homeowner looking to upgrade their door security solutions.
Rim Exit Device 48 Inch
Advantex Wide Stile Rim Exit Device, with Night Latch Trim, Less Dogging, 99 Surface Strike, 48″ Device, Satin Stainless Steel Finish
The 10 Series rim exit device is super-heavy-duty panic and fire exit hardware for use on all types of single and double doors with mullions. The patented mounting plate and strike locator system ensures the easiest and most accurate installation of panic hardware available.
Superior heavy duty exit devices.
Attributes
Base Material: Stainless Steel
Commercial Residential: Commercial
Device Length: 48″
Device Type: Rim
Dogging Options: Less Dogging
Finish: 630/US32D
Finish Family: Matte Silver
Fire Rated: No
Includes Trim: Yes
Installation: Commercial
Physical Appearance: Wide Stile Pushpad
Series: Detex Advantex Exit Devices
Subtype: Rim Exit Devices
Trim Type: Night Latch, Pull
Type: Exit Devices
