Description
Sargent 8270-24V 3 24VDC Electrified Lock Body
Sargent 8270-24V 3 Electrified Lock Body 24VDC offers an advanced electro-mechanical fail-safe function, ensuring maximum security for your premises. Constructed from high-quality components, this single cylinder lock body is finished in bright brass, making it not only durable but also aesthetically pleasing. Designed for standard door thicknesses of 1-3/4″ (44mm), the lock features a robust 12-gauge heavy-duty wrought steel case with zinc dichromate plating, ensuring longevity and resilience. The lock’s 3/4″ (19mm) stainless steel latchbolt is reversible and anti-friction, providing smooth operation. Its one-piece hardened stainless steel deadbolt offers an additional layer of security with a 1″ (25mm) projection. The Sargent 8270 series is masterkeying capable and can be customized with various finishes, including options like ANSI Standard A115.1 for strikes. The lock is designed to be easily field reversible, accommodating different hand specifications. With a 10-year limited warranty and a 2-year warranty on electrified components, you can trust the reliability of this product. For added convenience, it operates on 12VDC or 24VDC and is suitable for a variety of applications, combining strength, flexibility, and innovative security solutions in one.
Electrified Lock Body 24VDC
Lock Body Only, Electro Mechanical Fail Safe Function, Single Cylinder, Bright Brass
Designed and constructed with high quality components to provide maximum security.
The Sargent electrified 8270 series locks represent over a century of innovation and experience in manufacturing hardware and are the industry’s benchmark for mortise locks: Strong – Durable – Flexible – Innovative and Secure.
- For Doors 1-3⁄4″ (44mm) thick standard. For doors over 1-3⁄4″ (44mm), specify door thickness and panels (if any)
- Backset 2-3⁄4″ (70mm) only
- Case 12 gauge heavy duty wrought steel, zinc dichromate plated. Thickness 7/64″ (3mm) (.109″)
- Outside Front Plate Brass, bronze or stainless steel. 8″ (203mm) x 1-1⁄4″ (31mm), ANSI Standard A115.1. Adjustable at any angle from flat to beveled 1⁄8″ (3mm) in 2″ (51mm)
- Springs High carbon steel
- Hubs for Knobs Sintered iron copper infiltrated
- Hubs for Levers Cold forged steel
- Hubs for Institutional Stainless steel (3- prefix)
- Latchbolt Stainless steel 3⁄4″ (19mm) projection one-piece, anti-friction reversible latch
- Auxiliary Deadlatch Stainless steel, non-handed
- Deadbolt One-piece hardened stainless steel, with 1″ (25mm) projection
- Hand Specify hand on order; easily field reversible (if no hand is specified RH will be provided)
- Strike Brass, bronze or stainless steel; ANSI Standard A115.1; curved lip, non-handed (strike box optional)
- Keys Two, nickel silver (control key or emergency key must be ordered when required)
- Cylinder Brass, size #41 (1-1/8″) standard (except for Freewheeling, size #46 (1-3/4″)). Available with SARGENT Signature, V-10, XC and KESO Security Systems
- Masterkeying Can be masterkeyed or grand masterkeyed. Construction keying available. LA standard keyway.
- Finishes 3, 4, 9, 10, 10B, 10BL,15, 20D, 26, 26D, 32, 32D Special finishes are available. (Contact factory for details)
- Classroom Security 38, 39, 40, 41 Functions (All mortise trim designs available except KE/LE 3 & 4 and PT trim or FE trim with 41 function)
- Stile 4-1/2″ (114mm) minimum stile for 7800/8200, 4-3/4″ (121mm) minimum stile for electrical function locks
- Door Prep ANSI A115.1 modified per template (see template for 7800/8200 lockbody & trim)
- Warranty 10 year limited warranty, 2 year limited warranty on electrified locks
Attributes
Amp Draw: 0.015 Amp
Baa Qualified: Yes
Bolt Projection: 3/4 In.
Country of origin: USA
Door Thickness: 1-3/4 In.
Dust Box: None
Finish: 605/US3
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 70-Electrical Fail Safe
Grade: Grade 1
Limited Warranty: 2 Years
Lock Face Size: 8 In. X 1-1/4 In.
Operating Voltage: 12VDC/24VDC
Origin: USA
Pack Qty: 1
Power: Hard Wired
Screws: Combination
Series: 8270 Series Electrified Lever Mortise Locks
Side Locked: Outside
Std Latch Type: Guarded Latch
Std Strike Height: 4-7/8 In.
Std Strike Number: 82-0110
Std Strike Type: ASA
Std Strike Width: 1-1/4 In.
Subtype: Electric Mortise Lock
Switch Type: None
Type: Electric Locks
Unit of Measure: Each
