Description
Marks Hardware 195B/26D Cylindrical Lock
Marks USA Survivor Series locksets are the most durable cylindrical lever locksets. The Survivor Series locksets are backed by Marks lifetime mechanical warranty. All functions are available in six standard finishes, are UL Listed for 3-hour fire rating, and satisfy ADA requirements.
Attributes
Accessible: Yes
Ada Compliance: Yes
Alternate Codes: 195B26D
Ansi: A156.2
Ansi Function: F82A
Baa Qualified: Yes
Backset: 2-3/4″
Bolt Projection: 9/16″
Burglar Rated: No
Category: Commercial Locks, Cylindrical Levers, Lock Sets
Certifications: A156.2, ANSI, UL Listed 3 Hour
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Cylinder Type: Conventional
Door Application: Lock Sets
Door Thickness: 1-5/8″-1-7/8″
Finish: 626/US26D
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Finish : Satin Chrome
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 120 min
Function: Entry
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Keying: Keyed Different
Keys: Cut
Latch Throw: 9/16″
Latchbolt Type: Deadlatch
Lever Design: American
Leverknob Design: 195 – American Lever
Limited Warranty: Lifetime
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer: Marks USA
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Restrictions: None
Rose/ Escutcheon: 3-7/16″ Diameter, Spring Loaded
Roseescutcheon Design: 3-7/16″ Rose Diameter
Screws: Combination
Series: 95 Line
Std Keyway: Schlage C
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 1834
Std Strike Height: 4-7/8″
Std Strike Number: 1135
Std Strike Type: ASA Curved Lip Strike
Std Strike Width: 1-1/4″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL 10C
Unit of Measure: Each
Resources
- Marks Survivor Series Cylindrical Locksets Cut Sheet
