Description
Schlage F51A ACC 609 ADD KD F-Series Entry Lock Instructions
Schlage Residential F51A ACC 609 ADD KD F-Series Entry Lock combines classic elegance with modern functionality, making it an ideal choice for both residential single-family and multi-family doors. Featuring the stylish Accent lever and the Addison rose design in an antique brass finish, this entry lock enhances the aesthetic of any home décor while providing secure access. Crafted from durable brass, the F51A lock meets ANSI A156.2 standards and is certified as Grade 2, ensuring reliable performance for everyday use. Its universal latch design accommodates both 2-3/8″ and 2-3/4″ backsets, with a door thickness range of 1-3/8″ to 1-3/4″, making installation seamless and adaptable for various door types.The lock is not only aesthetically pleasing but also functional, being ADA compliant and available for up to three-hour fire doors. With an easy 3-step installation that requires only a screwdriver, homeowners can quickly upgrade their security with minimal effort.Schlage’s F51A ACC 609 ADD KD entry lock is the perfect blend of style and security, ensuring that your home remains both beautiful and safe.
F-Series Entry Lock
Entry Lock, Accent Lever, Addison Rose, Antique Brass
From classic looks that never go out of style to bold contemporary designs, Schlage’s levers and door handles fit and accentuate virtually any decor. Available in a variety of functions, you can choose the perfect look for every room in your house – it’s the easiest way to give your entire home a style upgrade.
Easy 3-step installation, only a screwdriver needed.
Schlage’s F Series designs range from bold to classic to match any residential décor. Plus, it features an easy 3-step installation, only a screwdriver needed.
- Applications: Residential single- and multi-family doors
- Certifications: ANSI A156.2, 1996, Series 4000 Grade 2
- U.L. Listed: Locks for up to three-hour fire doors available
- Door thickness range: 1-3/8″ to 1-3/4″ (35mm-44mm) standard
- Backset: Universal latch standard, fits either 2-3/8″ (60mm) or 2-3/4″ (70mm) backsets. 5″ (127mm) backset available
- ADA compliant: Yes
Attributes
Manufacturer surcharge: 6.5%
Base Material: Brass
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/8 In. – 1-3/4 In.
Finish: 609/US5
Function: F51A-Keyed Entry
Grade: Grade 2
Leverknob Design: ACC – Accent
Pack Qty: 1
Roseescutcheon Design: ADD – Addison
Series: F Series Residential Levers
Std Keyway: C
Subtype: Tubular Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
