Description
Falcon Lock T511LD LAT 626 Grade 1 Entry/Office Lock
Falcon T511LD LAT 626 Grade 1 Entry/Office Lock offers robust security and reliability for high-traffic areas. Designed as a Grade 1 cylindrical lock, this model excels in both performance and durability, making it ideal for institutional settings. The lock features a Latitude lever and comes in a sleek satin chrome finish, ensuring both style and functionality. Constructed to meet ANSI/BHMA Grade 1 standards, the T511LD is built with a compression spring mechanism that withstands heavy use and abuse. This lock accepts any manufacturer’s cylinder, allowing for easy re-keying and retrofitting in existing buildings-perfect for those looking to upgrade their security without extensive modifications.With a backset of 2-3/4 inches (also available in 2-3/8 inches), and capable of accommodating door thickness from 1-3/4 inches to 2-1/4 inches, this lock adapts seamlessly to various installations. The heavy wrought brass trim and solid lever ensure a sturdy grip and a professional appearance.Additionally, the T511LD is UL listed for fire safety and comes with a limited 10-year warranty, making it a reliable choice for commercial applications. When you need a dependable, high-quality lock, trust Falcon’s T511LD for peace of mind and superior performance.
Grade 1 Entry/Office Lock
Grade 1 Entry/Office Cylindrical Lock, Less Cylinder, Latitude Lever, Standard Rose, Satin Chrome Finish, Non-Handed
The T Series extra heavy-duty Grade 1 cylindrical lock is designed to stand up to high-traffic and heavy-abuse applications. The lock can accept any manufacturer⢬ìöâââìâìÃâìâôs cylinder, and the cylinder can easily be removed for quick, easy re-keying, so retrofitting a current building is simple. The T Series is constructed with a compression spring that allows the lock to exceed ANSI/BHMA Grade 1 testing requirements. Perfect for high-use institutional applications, the T Series lock delivers by providing a solid product at a solid price.
Can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying.
- Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
- Backset: 2-3/4” standard. 2-3/8” also available. Link (A22161-005-10) available for 5” backset.
- Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
- Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
- Handing: Locks are non-handed.
- Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. 7-pin cylinders also available. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard. Interchangeable core design is available for small format (SFIC) and large format for most manufacturers.
- Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
- Trim: Roses are heavy wrought brass or bronze, installed over pressure cast rose inserts which are through-bolted through door. Levers are pressure cast (solid levers–no inserts) material finished to match mating parts.
- Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
- Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
- Screws: Furnished with combination screws for use in wood or metal doors and frames.
- Electrified Functions: Available in 24 VDC .185 AMP.
Attributes
Manufacturer surcharge: 4.5%
Accessible: Yes
Ada Compliance: Yes
Ansi: ANSI/BHMA A156.2, Series 4000, Grade 1
Ansi Function: F109 – Entry/Office
Baa Qualified: Yes
Bolt Projection: 1/2″ Latch
Bore Hole Diameter: 2-1/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Type: Less Cylinder
Door Thickness: 1-3/4″ – 2-1/4″
Dust Box: None
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: T511-Entry/Office
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Bore Diameter: 1″
Leverknob Design: LAT – Latitude Lever
Leverknob Design Family: Straight Lever
Limited Warranty: 10 Years
Lock Face Size: 2-1/4″ x 1-1/8″
Origin: Mexico
Pack Height: 3.75″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 242.81 in³
Pack Width: 7″
Pbs Options: 10294577
Pins: 6
Projection: 3-1/2″
Restrictions: None
Roseescutcheon Design: Standard Rose
Roseescutcheon Dimensions: 3-1/2″ Rose Diameter
Screws: Combination
Series: T Series Grade 1 Cylindrical Lever Locks
Ship Weight: 5.5 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 23981145
Std Latch Type: Dead Latch (Guarded)
Std Strike Height: 4-7/8″
Std Strike Number: 5164
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: A Label
Unit of Measure: Each
