Description
Falcon Lock T101S Q 605 Grade 1 Passage Latch
Falcon Lock T101S Q 605 Grade 1 Passage Latch offers exceptional durability and reliability, making it an ideal choice for high-traffic environments. This Grade 1 cylindrical lock features a sleek Quantum lever and a standard rose design, finished in bright brass for a polished look. It is non-keyed and non-handed, allowing for versatile installation on doors ranging from 1-3/4″ to 2-1/8″ thick. Constructed to exceed ANSI/BHMA Grade 1 testing standards, the T Series lock is built with a compression spring mechanism, ensuring longevity even under heavy use. The lock can accept cylinders from any manufacturer, and its easily removable design allows for quick re-keying, making it a practical choice for retrofit applications. Additional features include a 9/16″ bolt projection latch, ANSI strike compliance, and stainless steel springs for enhanced rust resistance. The heavy wrought brass or bronze roses are securely installed over pressure cast inserts, ensuring strength and stability. With a 10-year limited warranty, the Falcon T101S lock combines quality with value, making it a smart investment for both commercial and institutional settings.
Grade 1 Passage Latch
Grade 1 Passage/Closet Cylindrical Lock, Non-keyed, Quantum Lever, Standard Rose, Bright Brass Finish, Non-Handed
The T Series extra heavy-duty Grade 1 cylindrical lock is designed to stand up to high-traffic and heavy-abuse applications. The lock can accept any manufacturer⢬ìöâââìâìÃâìâôs cylinder, and the cylinder can easily be removed for quick, easy re-keying, so retrofitting a current building is simple. The T Series is constructed with a compression spring that allows the lock to exceed ANSI/BHMA Grade 1 testing requirements. Perfect for high-use institutional applications, the T Series lock delivers by providing a solid product at a solid price.
Can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying.
- Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
- Backset: 2-3/4” standard. 2-3/8” also available. Link (A22161-005-10) available for 5” backset.
- Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
- Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
- Handing: Locks are non-handed.
- Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. 7-pin cylinders also available. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard. Interchangeable core design is available for small format (SFIC) and large format for most manufacturers.
- Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
- Trim: Roses are heavy wrought brass or bronze, installed over pressure cast rose inserts which are through-bolted through door. Levers are pressure cast (solid levers–no inserts) material finished to match mating parts.
- Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
- Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
- Screws: Furnished with combination screws for use in wood or metal doors and frames.
- Electrified Functions: Available in 24 VDC .185 AMP.
Attributes
Manufacturer surcharge: 4.5%
Accessible: Yes
Ada Compliance: Yes
Ansi: ANSI/BHMA A156.2, Series 4000, Grade 1
Ansi Function: F75 – Passage
Baa Qualified: Yes
Bolt Projection: 1/2″ Latch
Bore Hole Diameter: 2-1/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Type: Non-keyed
Door Thickness: 1-3/4″ – 2-1/4″
Dust Box: None
Finish: 605/US3
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: T101-Passage/Closet
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Bore Diameter: 1″
Leverknob Design: Q – Quantum Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 10 Years
Lock Face Size: 2-1/4″ x 1-1/8″
Origin: Mexico
Pack Height: 3.75″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 242.81 in³
Pack Width: 7″
Projection: 3-1/4″
Restrictions: None
Roseescutcheon Design: Standard Rose
Roseescutcheon Dimensions: 3-1/2″ Rose Diameter
Screws: Combination
Series: T Series Grade 1 Cylindrical Lever Locks
Ship Weight: 5.5 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 23981137
Std Latch Type: Spring Latch (Unguarded)
Std Strike Height: 4-7/8″
Std Strike Number: 5164
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: A Label
Unit of Measure: Each
Resources
- Falcon Cylindrical Lock Guide
- T Series Data sheet
- T-Series Installation Instructions
- T-Series Installation Instructions – Electrical
- T-Series Sell Sheet
- T-Series Service Manual
- T/W Series Data Sheet
- Von Duprin Finishes Chart
