Description
Falcon Lock MA931CP6 626 Mortise Double Deadlock
Falcon MA931CP6 626 Mortise Double Deadlock offers exceptional security and reliability for a variety of commercial applications, including offices, hospitals, and educational institutions. This Grade 1, two-sided deadlock is designed to withstand frequent use while ensuring robust protection. The lock features a 6-pin conventional cylinder, making it easy to re-key and compatible with SFIC products from other manufacturers. Constructed from cold-formed steel with a zinc dichromate plating, the lock case is built to last. It accommodates standard door thicknesses from 1-3/8″ to 2-1/2″ and includes a field-reversible handing option, allowing for easy customization. The MA931 includes a solid brass cylinder with two nickel silver keys, and features a latch bolt with a 3/4″ projection and a stainless steel deadbolt with a 1″ throw. Designed for high performance, the lock meets ANSI/BHMA 156.13, Series 1000 standards, and is UL listed for a 3-hour fire rating. The heavy-duty trim uses through-bolted inserts for alignment, while the strike is non-handed and meets ANSI AII5.1 frame preparation specifications. Backed by Allegion, the Falcon MA931CP6 is a reliable choice for those seeking quality and durability in door hardware.
Mortise Double Deadlock
Grade 1 Two-Sided Deadlock Mortise Lock, 6-Pin Conventional Cylinder, Satin Chrome Finish, Field Reversible
The Falcon MA Series lock delivers high performance at an affordable cost for your office, hospital, education, or other commercial projects. One of Falcon’s toughest and most dependable locks, the MA Series, provides security and is built to stand up to constant use without fail. The MA Series also makes retrofit easy with an interchangeable core that can be removed for quick, easy re-keying and is compatible with SFIC products from other manufacturers. Plus they’re backed by one of the best names in the business – Allegion.
Provides security and is built to stand up to constant use without fail.
- Door thickness:Standard accommodates thickness of 1-3/8” to 2-1/2”.
- Backset:2-3/4” only.
- Case:Cold formed steel, zinc dichromate plated, .090” thick. Optional lead wrapping available.
- Hubs:Hardened steel.
- Handing:Right hand is standard; left hand optional. Reversible in the field.
- Cylinders:Solid brass cylinder and plug. 5, 6 or 7-pin are available on standard cylinders. 6 or 7-pin are available on interchangeable core cylinder. Furnished with two nickel silver keys standard
- Keyways:“G” keyway standard on standard cylinder. “A” keyway standard on I/C cylinder. See price book for optional keyways
- Bind Resistant Trim:Heavy-duty through-bolted inserts clamp the trim on the door assuring proper alignment. Provided with 8-32 screws for strength and thread sealant to prevent loosening.
- Latch Bolt:Two-piece stainless steel, mechanical anti-friction bolt. 3/4” projection.
- Dead Bolt:1” throw, stainless steel with two 13/16” diameter hardened steel, free-turning, saw-resistant roller.
- Faceplates:(Armored Front) 1-1/4” x 8” brass or stainless steel adjustable for door bevel. Reinforced by heavy gauge steel with stabilizing ribs.
- Strike:Brass or stainless steel. Meets ANSI AII5.1 for frame preparation. Strike is non-handed.
- Electrified Functions:Available in 12 or 24 VDC.
- ANSI/BHMA:Meets ANSI/BHMA 156.13, Series 1000.
- UL:3 hour A label.
Attributes
Manufacturer surcharge: 4.5%
Ansi: ANSI/BHMA 156.13 Series 1000 Grade 1
Ansi Function: F16 – Double Deadlock
Base Material: Brass or Bronze
Bolt Projection: 1″ Bolt
Bolt Throw: 1″ Bolt
Cam Number: 5622
Commercial Residential: Commercial
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4″ to 1-7/8″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: MA931-Two-Sided Deadlock
Function Family: Institution
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Keying: Keyed Different
Keys: Cut
Latch Backset Dim: 2-3/4″
Latch Backset Dimension: 2-3/4″
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Pack Qty: 1
Pbs Options: 10294557
Pins: 6
Screws: Combination
Series: MA Series Grade 1 Mortise Locks
Std Keyway: C
Std Latch Backset Dim: 2-3/4″
Std Latch Type: Deadbolt
Std Strike Height: 4-7/8″
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Resources
- MA Series Grade 1 Mortise Locks Cut Sheet
- MA-Series Installation Instructions
- MA-Series Sell Sheet
- MA-Series Service Manual
- Video: Falcon MA Mortise Lock Installation
- Von Duprin Finishes Chart
