Description
Falcon Lock F-25-M-EO 3 19 LHR Mortise Exit Device, Exit Only 3′
Falcon Lock F-25-M-EO 3 19 LHR Mortise Exit Device is a Grade 1, fire-rated exit bar designed to enhance safety and security in high-traffic areas. Featuring a wide stile pushpad and a sleek matte black finish, this 36″ exit-only device not only meets aesthetic demands but also offers robust performance. The left-hand reverse handing makes installation straightforward, ensuring that it fits seamlessly into your building design. Engineered to withstand frequent use, the Falcon 25-M series combines a reliable exit mechanism with a durable mortise lock, providing peace of mind without compromising on style. Its patent-pending deadlocking technology adds an extra layer of security, making it an ideal choice for offices, churches, retail spaces, and more. The device is adaptable for various applications, whether new construction or retro-fitting existing doors made of wood or metal. With an ANSI rating of A156.3-2001, it meets commercial standards, ensuring long-lasting durability. The F-25-M-EO is also available with electrified options and panic functionality, giving you maximum flexibility in a variety of settings. Choose Falcon for a smart, secure solution that prioritizes safety while seamlessly integrating into your architectural design.
Mortise Exit Dev, Exit Only 3′
Grade 1 Mortise Exit Bar, Wide Stile Pushpad, 36″ Fire Rated Device, Exit Only Function, Less Trim, Less Dogging, Matte Black Finish, Left Hand Reverse
The Falcon 25-M Series is the only device that pairs a tough, reliable exit device with our strongest mortise lock. The result is maximum safety and security in a single-point, mortise latch type device that also has an attractive touch bar design.
Architectural wide-stile push pad exit devices providing quality and durability at an affordable price.
A host of features makes this a smart solution, like a choice of an A or B label fire rating, electrified and panic options, and a full complement of trims. Sleek, streamlined styling and a choice of wide-stile device applications means a smart solution for your building design, as well as its use.
Features:
- Maximum flexibility in a variety of applications
- Wide range of features and options
- Patent pending deadlocking technology
Applications:
- Frequent traffic
- Offices, churches, hospitality, retail, education, healthcare
- Interior, exterior, new construction, retro-fit
Attributes
Manufacturer surcharge: 4.5%
Ansi: A156.3-2001
Commercial Residential: Commercial
Device Length: 36″
Device Type: Mortise
Dogging Options: Less Dogging
Door Material: Wood or Metal
Door Thickness: 1-3/4″
Finish: 622/US19
Finish Family: Black
Fire Rated: Yes
Fire Rating: Yes {Variable}
Grade: Grade 1
Handing: Left Hand Reverse
Includes Cylinders: No
Includes Trim: No
Installation: Commercial
Mechanical Function: Exit Only
Minimum Stile Size: 4-1/2″
Pack Qty: 1
Physical Appearance: Wide Stile Pushpad
Reversible: Yes
Series: 25 Series Exit Devices
Strike Standard: 1279
Subtype: Mortise Exit Devices
Trim Type: Less Trim
Type: Exit Devices
Ul Listing: A Label (3 hr.); 4’0″ x 10’0″ Single Doors; 8’0″ x 10’0″ Pair of Doors (F-25-M x F-25-V or F-25C). “B” Label (1-1/2 hr.) with F1280 Open Back Strike.
Unit of Measure: Each
Resources
- 19, 24, 25 and XX Series Exit Devices Service Manual
- 24 Series / 25 Series Sell Sheet
- 25 Series Exit Devices Cut Sheet
- 25-C Installation Instructions
- 25-M Installation Instructions
- 25-R Installation Instructions
- 25-V Installation Instructions
- 25-WDC Installation Instructions
- 510L-NL/510L-DT 513K-NL/513K-DT Installation Instructions
- Falcon Motorized Electric Latch Retraction Kit Data Sheet
- Video: Falcon 25R Rim Exit Device Installation
- Von Duprin Finishes Chart
