Description
Falcon Lock 19-R-KIL-NL SP313 3 LHR Rim Exit Device with Nightlatch 3′
Falcon Lock 19-R-KIL-NL SP313 3′ Rim Exit Device offers a reliable solution for light- to medium-duty door applications. Designed with a narrow stile pushpad and equipped with hex key dogging, this Grade 1 exit device is perfect for both interior and exterior single or double doors where traffic is moderate. The lever night latch mechanism adds an extra layer of security, making it suitable for commercial, multi-family, office, and retail environments. At a length of 36 inches, the Falcon 19 series seamlessly fits doors with widths ranging from 29″ to 36″ and a thickness of 1-3/4″. Its versatile design allows for easy installation on metal or wood doors, and it is reversible to accommodate left-hand reverse configurations. The device features a dark bronze painted finish, ensuring a stylish addition to any setting. With seven functions and four lever designs available, users can customize the device to meet their specific needs. This dependable exit device comes with a 10-year warranty, reinforcing its durability and reliability. The Falcon Lock 19-R-KIL-NL is not just an exit device; it’s a trusted partner in safety and accessibility.
Rim Exit Device, Nightlatch 3′
Grade 1 Rim Exit Device, Narrow Stile Pushpad, Hex Key Dogging, Nightlatch Lever, Dane, 36″, Left Hand Reverse, Dark Bronze Painted Finish
The 19 Series narrow stile exit devices provide value and dependability on light- to medium-duty door applications. They can be mounted on interior or exterior single or double doors, where traffic is not consistently heavy.
Lowest cost most dependable light-duty exit device.
- Rim, SV
- 7 functions /4 lever designs
- 3 finishes
- 10-year warranty
- Moderate traffic
- Commercial, multi-family, office, retail
- Interior, exterior, retro-fit
Attributes
Manufacturer surcharge: 4.5%
Commercial Residential: Commercial
Cylinder Type: Key-in-Knob/Key-in-Lever
Device Length: 36″
Device Type: Rim
Dogging Options: Hex Key Dogging
Door Material: Metal or Wood
Door Thickness: 1-3/4″
Door Width: 29″ to 36″
Finish: 695
Fire Rated: No
Grade: Grade 1
Handing: Left Hand Reverse
Includes Cylinders: Yes
Includes Trim: Yes
Installation: Commercial
Mechanical Function: Lever Night Latch
Minimum Stile Size: 1-3/4″
Pack Qty: 1
Physical Appearance: Narrow Stile Pushpad
Reversible: Yes
Series: 19 Series Exit Devices
Strike Standard: F570
Subtype: Rim Exit Devices
Trim Design: Dane
Trim Part No: 914KIL-NL
Trim Type: Night Latch, Lever
Type: Exit Devices
Unit of Measure: Each
Resources
- 1490 Series Exit Devices;1590 Series Exit Devices; 1690 Series Exit Devices;1790 Series Exit Devices;19 Series Exit Devices Cut Sheet
- 19 Series Exit Device Template Index Wood Door Applications
- 19 Series Exit Devices Cut Sheet
- 19 Series Supplement to Installation Instructions
- 19, 24, 25 and XX Series Exit Devices Service Manual
- 19-V Installation Instructions
- 19-V-LBR Installation Instructions
- F-19-R & 19-R Installation Instructions
- Falcon Medium Duty Commercial Pushpads Catalog
- Medium Duty Commercial Pushpads
- Von Duprin Finishes Chart
