Description
Schlage L9093EUL 06L 626 RX Grade 1 Electric Both Levers, No DB
Schlage L9093EUL 06L 626 RX Grade 1 Elec Both Lvrs, noDB is a robust electric mortise lock designed for commercial applications, meeting the highest security standards with its Grade 1 rating. This fail secure model ensures that, in the event of a power failure, the lock remains secured, providing peace of mind for building managers and owners alike. Crafted with a satin chromium plated finish, the L9093EUL boasts a sleek and modern appearance, seamlessly integrating into various architectural styles. The lock features a field-reversible design, allowing for flexible installation on left or right-handed doors. With a universal input voltage that accommodates both 12VDC and 24VDC, installation is straightforward and user-friendly. The innovative RX switch enhances security by monitoring the inside lever, balancing sensitivity and detection. Additionally, it can be easily added in the field without the need to disassemble the lock case. The lock supports a door thickness of 1-3/4″ and includes a request-to-exit function, making it an ideal choice for high-traffic areas. With an amp draw of 400mA and compliance with ADA standards, the Schlage L9093EUL is not only secure but also accessible, ensuring it meets diverse building needs.
Grade 1 Elec Both Lvrs, noDB
Grade 1 Fail Secure Electric Mortise Lock, Less Cylinder, 06 Lever, L Escutcheon, Request to Exit, Satin Chromium Plated Finish, Field Reversible
The Schlage L909x Series is the next generation of electrified mortise lock. The series utilizes the latest technology to offer tremendous utility and flexibility. The universal input voltage will accept 12 or 24VDC and fail safe/fail secure functions are user selectable in the field by flipping a switch in the lock case. The all new RX switch monitors the inside lever with enhanced detection level that balances security with lever sensitivity, and can be added in the field without opening the lock case.
Attributes
Accessible: Yes
Ada Compliance: Yes
Amp Draw: 400mA
Base Material: Brass or Bronze
Bolt Projection: 3/4″
Category: Commercial Electric Locks, Deadbolts, Electric Locks, Lock Sets, Mortise Electric, Mortise Electric Locks, Mortise Locks, Standalone/Pushbutton Locks
Commercial Residential: Commercial
Cylinder Type: Less Cylinder
Door Thickness: 1-3/4″
Dust Box: Plastic
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 9093EU-Fail Secure
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Leverknob Design: 06 Lever
Limited Warranty: 1 Year
Lock Face Size: 8″ x 1-1/4″
Operating Voltage: 12VDC/24VDC
Pack Qty: 1
Power: Hard Wired
Roseescutcheon Design: L Escutcheon
Screws: Combination
Series: L9090 Series Electrified Mortise Lock
Std Strike Height: 4-7/8″
Std Strike Number: 10-072
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Electric Mortise Lock
Switch Type: Request to Exit
Type: Electric Locks
Unit of Measure: Each
