Description
Schlage L9092EUJ LATB 622 Grade 1 Electric Fail Secure No Database Lock
Schlage L9092EUJ LATB 622 Grade 1 Elec noDB, Fail Sec is a robust electric mortise lock designed for commercial applications. With its Grade 1 certification, this lock guarantees superior strength and durability, ensuring reliable security for your premises. The fail secure feature adds an extra layer of protection, making it ideal for environments where security is paramount. This model accepts universal input voltage of 12 or 24VDC, allowing for easy integration into various electrical systems. The user-selectable fail safe/fail secure function can be adjusted in the field with a simple switch, providing flexibility to meet specific security needs. The innovative RX switch enhances the detection of the inside lever, balancing security with user convenience, and can be installed without the need to open the lock case. The Latitude lever design, paired with a sleek flat black coated finish, offers a modern aesthetic that complements any door. Field reversible handing and compatibility with Schlage FSIC prep less core cylinders enhance its versatility. With a 3/4″ bolt projection and a fire rating of 3 hours, this lock is engineered for both safety and performance. Backed by a 1-year limited warranty, the Schlage L9092 is the ideal choice for those seeking reliable, high-quality door hardware.
Grade 1 Elec noDB, Fail Sec
Grade 1 Fail Secure Electric Mortise Lock, Schlage FSIC Prep Less Core, Latitude Lever, B Rose, Flat Black Coated Finish, Field Reversible
The Schlage L909x Series is the next generation of electrified mortise lock. The series utilizes the latest technology to offer tremendous utility and flexibility. The universal input voltage will accept 12 or 24VDC and fail safe/fail secure functions are user selectable in the field by flipping a switch in the lock case. The all new RX switch monitors the inside lever with enhanced detection level that balances security with lever sensitivity, and can be added in the field without opening the lock case.
Attributes
Manufacturer surcharge: 4.5%
Accessible: Yes
Ada Compliance: Yes
Amp Draw: 400mA
Bolt Projection: 3/4″
Commercial Residential: Commercial
Cylinder Type: Schlage FSIC Prep Less Core
Door Thickness: 1-3/4″
Dust Box: Plastic
Finish: 622/US19
Finish Family: Black
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 9092EU-Fail Secure
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Leverknob Design: LAT – Latitude Lever
Limited Warranty: 1 Year
Lock Face Size: 8″ x 1-1/4″
Operating Voltage: 12VDC/24VDC
Pack Qty: 1
Power: Hard Wired
Roseescutcheon Design: B Rose
Screws: Combination
Series: L9090 Series Electrified Mortise Lock
Std Strike Height: 4-7/8″
Std Strike Number: 10-072
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Electric Mortise Lock
Type: Electric Locks
Unit of Measure: Each
