Sargent RXLC-8271-24V LNL 10 Grade 1 Electric No DB Fail Secure Instructions
Sargent RXLC-8271-24V LNL 10 Grade 1 Elec No DB, Fail Sec is a premium fail secure, 24V electrified mortise lock designed to offer robust security for your building. With its innovative Ecoflex Technology, this lock can easily be configured for fail safe or fail secure operations and is compatible with 12V to 24V power supplies. It is ideal for single opening, standalone applications and integrates smoothly with advanced access control systems. Meeting ANSI/BHMA A 156.13 Grade 1 standards, the Sargent RXLC-8271 is UL listed for fire doors and meets rigorous industry standards for temperature, shock, and fire hazards. Crafted from heavy-duty 12-gauge wrought steel, the lock features a satin bronze finish and comes with a robust 3/4″ stainless steel latchbolt and a hardened stainless steel deadbolt for maximum security. Designed for 1-3/4″ thick doors, the RXLC-8271 is field reversible and accommodates various handing specifications. Its ANSI standard strike is non-handed, making installation straightforward. This lock also offers versatility in master keying options, allowing for tailored security solutions. With a limited 2-year warranty on electrified components, the Sargent RXLC-8271 is a durable and reliable choice for any security-conscious environment.
Grade 1 Elec No DB, Fail Sec
Fail Secure, 24V Electrified Mortise Lock, LN Rose, L Lever, Less Cylinder, RX Switch, Satin Bronze
Featuring Ecoflex Technology, Sargent 8200 Electromechanical Mortise Locks are field changeable between fail safe and fail secure functions and operate off 12v through 24v power. They are designed to handle single opening, stand alone applications. They can also be readily integrated into sophisticated access control systems. They meet ANSI/BHMA A 156.13 Grade 1 requirements, are UL listed on fire doos and sitisfy industry standards for operating temperature, shock and fire hazard.
Designed and constructed with high quality components to provide maximum security.
The Sargent electrified 8270 series locks represent over a century of innovation and experience in manufacturing hardware and are the industry’s benchmark for mortise locks: Strong – Durable – Flexible – Innovative and Secure.
- For Doors 1-3⁄4″ (44mm) thick standard. For doors over 1-3⁄4″ (44mm), specify door thickness and panels (if any)
- Backset 2-3⁄4″ (70mm) only
- Case 12 gauge heavy duty wrought steel, zinc dichromate plated. Thickness 7/64″ (3mm) (.109″)
- Outside Front Plate Brass, bronze or stainless steel. 8″ (203mm) x 1-1⁄4″ (31mm), ANSI Standard A115.1. Adjustable at any angle from flat to beveled 1⁄8″ (3mm) in 2″ (51mm)
- Springs High carbon steel
- Hubs for Knobs Sintered iron copper infiltrated
- Hubs for Levers Cold forged steel
- Hubs for Institutional Stainless steel (3- prefix)
- Latchbolt Stainless steel 3⁄4″ (19mm) projection one-piece, anti-friction reversible latch
- Auxiliary Deadlatch Stainless steel, non-handed
- Deadbolt One-piece hardened stainless steel, with 1″ (25mm) projection
- Hand Specify hand on order; easily field reversible (if no hand is specified RH will be provided)
- Strike Brass, bronze or stainless steel; ANSI Standard A115.1; curved lip, non-handed (strike box optional)
- Keys Two, nickel silver (control key or emergency key must be ordered when required)
- Cylinder Brass, size #41 (1-1/8″) standard (except for Freewheeling, size #46 (1-3/4″)). Available with SARGENT Signature, V-10, XC and KESO Security Systems
- Masterkeying Can be masterkeyed or grand masterkeyed. Construction keying available. LA standard keyway.
- Finishes 3, 4, 9, 10, 10B, 10BL,15, 20D, 26, 26D, 32, 32D Special finishes are available. (Contact factory for details)
- Classroom Security 38, 39, 40, 41 Functions (All mortise trim designs available except KE/LE 3 & 4 and PT trim or FE trim with 41 function)
- Stile 4-1/2″ (114mm) minimum stile for 7800/8200, 4-3/4″ (121mm) minimum stile for electrical function locks
- Door Prep ANSI A115.1 modified per template (see template for 7800/8200 lockbody & trim)
- Warranty 10 year limited warranty, 2 year limited warranty on electrified locks
Attributes
Amp Draw: 500mA Peak, 15mA Holding
Application: Complete Lock
Baa Qualified: Yes
Base Material: Bronze
Bolt Projection: 3/4″
Country of origin: USA
Cylinder Type: Less Cylinder
Door Thickness: 1-3/4″
Finish: 612/US10
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 71-Electrical Fail Secure
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: L Lever
Limited Warranty: 2 Years
Lock Face Size: 8″ X 1-1/4″
Operating Voltage: 12VDC/24VDC
Origin: USA
Pack Height: 4.38″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 227.64 in³
Pack Width: 5.63″
Power: Hard Wired
Roseescutcheon Design: LN Rose (2″ Diameter)
Screws: Combination
Series: 8270 Series Electrified Lever Mortise Locks
Ship Weight: 6.1 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 82-0110
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Electric Mortise Lock
Switch Type: RX
Type: Electric Locks
Unit of Measure: Each
