Description
Schlage L9026P 06B 626 Grade 1 Exit Device with Cylinder
Schlage L9026P 06B 626 Grade 1 Exit with Cylinder is a robust solution for high-traffic environments requiring reliable security. This Grade 1 exit lock features a conventional cylinder with an S123 keyway, designed for durability and dependability in settings such as schools, hospitals, and factories. The lock’s satin chrome finish not only enhances its aesthetic appeal but also ensures longevity against wear and tear. Engineered with an extra heavy-duty mortise lock, the Schlage L9026P is constructed from heavy-gauge steel, providing protection against door edge attacks. Its all-metal components, including zinc dichromate-plated working parts, contribute to its resilience. The lock’s innovative design features a break-away spindle to prevent unsecured failures, while a spring-loaded fusible link ensures fail-secure operation during fire emergencies. Adaptability is a key benefit, with a universal lock case that supports ten different functions and field-reversible handing for easy installation. The simple trim retrofit process and independent lever rotation enhance user convenience. Additionally, the locking thumb-turn provides clear visibility on the door’s status. With a limited three-year warranty, the Schlage L9026P is a trusted choice for those seeking exceptional security and performance.
Grade 1 Exit with Cylinder
Grade 1 Exit Lock with Cylinder Mortise Lock, Conventional Cylinder, S123 Keyway, 06 Lever, B Rose, Satin Chrome Finish, Field Reversible
Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
Extra heavy duty mortise lock protected by all metal heavy-gauge steel.
Schlage L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse.
Durability and Strength
- Heavy-gauge, fully wrapped steel case protects against door edge attacks
- All-metal zinc dichromate-plated working parts
- Electronic components protected by inside lock case
- Wear and tear reduced by two-piece anti-friction tongue
- Outside and inside trim thru-bolted together and through the door
Built-in Security
- Unsecured failures prevented by break-away spindle, also providing easy spindle replacement
- Spindle manipulation discouraged by hub blocking plate
- Spring-loaded fusible link provides fail secure mode in case of fire
- Inside lever applied by screwless shank mounting – no exposed trim mount screws
Adaptable to your application
- Universal lock case featuring ten functions in one case
- Floating mounting tabs adjust to fit a beveled door edge
- Field-reversible handing without opening lock case
- Simple trim retrofit made possible by external spring cages
- Locking thumb-turn on the inside of door shows when the door is unlocked and locked
- Lever rotation in both directions for ease of use
- Independent lever rotation
Attributes
Manufacturer surcharge: 4.5%
Ansi: A156.13-2017 Series 1000
Bolt Projection: 3/4″ Latch
Burglar Rated: No
Cam Number: L583-254
Cam Type: Schlage L
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Length: 1-1/8″
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 9026-Exit Lock with Cylinder
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Keying: Keyed Different
Keys: Cut
Leverknob Design: 06 Lever
Leverknob Design Family: Straight Return Lever
Limited Warranty: 3 Years
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Origin: Mexico
Pack Qty: 1
Pins: 6
Projection: 2-1/2″
Roseescutcheon Design: B Rose
Roseescutcheon Dimensions: 2-9/16″
Series: L9000 Series Mortise Lock
Std Keyway: S123
Std Latch Backset Dim: 2-3/4″
Std Latch Type: Dead Latch (Guarded)
Std Strike Height: 4-7/8″
Std Strike Number: 10-072 1316 626
Std Strike Type: ANSI Strike
Std Strike Width: 1-3/16″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Resources
- L Series Mounting Plate Installation Instructions
- L400 Installation Instructions
- L9000 Indicator Handing Instructions
- L9000 Indicator Lever w/ Escutcheon Installation Instructions
- L9000 Indicator Lever w/ Sectional Installation Instructions
- L9000 Installation Instructions
- L9000 Knob Installation Instructions
- L9000 Series Mortise Lock Cut Sheet
- Schlage L Indicator Data Sheet
- Schlage L Series Parts Diagram
- Schlage L Series Service Manual
- Schlage L9000 Gen 2 Indicator Pricing Addendum
- Video: AL Lock Installation
- Von Duprin Finishes Chart
