Description
Von Duprin CXA9875EO 3 15 Grade 1 MTS Exit Device 619 Instructions
Von Duprin CXA9875EO 3 15 Grade 1 Mts Exit Device 619 offers a robust and reliable solution for secure egress in commercial settings. This Grade 1 Delayed Egress Exit Device is designed with a wide stile pushpad and measures 36 inches, making it suitable for exit-only applications. With a satin nickel plated clear coated finish, this device not only enhances security but also adds a sleek, modern touch to your doors. Engineered for versatility, the CXA9875EO is non-handed and fits stock hollow metal doors with an 86 cutout and stiles as narrow as 4-3/4 inches. Its 7500 Mortise lock features a 3-4 inch anti-friction latch bolt that can be field-reversed without removing the lock, ensuring ease of installation and maintenance. The device is UL listed for panic exit hardware, providing confidence in safety during emergencies. This exit device incorporates a delayed egress feature, allowing a 15-second exit delay, which is ideal for high-security environments. The mechanism operates smoothly and accommodates door thicknesses from 1-3/4 inches to 2-1/4 inches. Overall, the Von Duprin CXA9875EO delivers both security and functionality, making it an excellent choice for professionals looking to enhance safety in their buildings.
Grade 1 Mts Exit Device 619
Grade 1 Delayed Egress Exit Device, Wide Stile Pushpad, 36″, Exit Only, Less Trim, Less Dogging, Delayed Egress Device 15 Seconds, Satin Nickel Plated Clear Coated Finish, Non-Handed
9875/9975 Mortise lock device for all types of single or double doors, UL listed for panic exithardware. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 3âÂÂâìàìÃÂ4″ (121mm). The 7500 Mortise lock is equipped with a 3âÂÂâìàìÃÂ4″ (19mm) anti-friction latch bolt which is fieldreversible without removing the lock from the door. It has a non-handed auxiliary bolt fordeadlocking and a faceplate with an adjustable bevel.
Fire exit mortise lock devices with a smooth mechanism case.
The 9875 Series is for all types of single or double doors and is UL listed for panic exit hardware. Devices are ANSI A156.3 – 2008 Grade 1. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4-3/4″ (121mm).
- Device Functions:Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
- Device Lengths:
- 3′ –2′ 4″to 3′ (711 mm to 914 mm) door size
- 4′ –2′ 10″ to 4′ (864 mm to 1219 mm) door size
- Device centerline from finished door:
- 39-13/16″ (1011 mm)
- 39-11/16″ (1008 mm) with mullion
- Center case dimensions:8″ x 2-3/4″ x 2-3/8″ (203 mm x 70 mm x 60 mm)
- Mechanism case dimensions:2 1/4″ x 2 1/4″ (57 mm x 57 mm)
- Projection:Pushbar neutral – 3-13/16″ (97 mm); Pushbar depressed – 3-1/16″ (78 mm)
- Fasteners & sex bolts (SNB):Includes screw pack for 1-3/4″ (44 mm) and 2-1/4″ (57 mm) thick metal or wood doors.
Attributes
Manufacturer surcharge: 4.5%
Accessible: No
Ada Compliance: No
Ansi: A156.3 2014
Baa Qualified: Yes
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: USA
Device Length: 36″
Device Type: Mortise
Dogging Options: Less Dogging
Door Material: Wood or Metal
Door Thickness: 1-3/4″ – 2-1/4″
Door Width: 28″ to 36″
Electric Options: Delayed Egress Device 15 Seconds
Finish: 619/US15
Finish Family: Matte Silver
Fire Rated: No
Fire Rating: No
Grade: Grade 1
Handing: Non-Handed
Includes Cylinders: No
Includes Trim: No
Installation: Commercial
Limited Warranty: 1 Year
Mechanical Function: Exit Only
Minimum Stile Size: 4-3/4″
Origin: USA
Pack Height: 10.5″
Pack Height 2: 11.75″
Pack Length: 37″
Pack Length 2: 41″
Pack Qty: 1
Pack Volume: 1942.5 in³
Pack Volume 2: 7708 in³
Pack Width: 5″
Pack Width 2: 16″
Physical Appearance: Wide Stile Pushpad
Product Height: 8″
Product Length: 33″
Product Width: 3.75″
Restrictions: None
Reversible: Yes
Series: 9875 Series Mortise Exit Device
Ship Weight: 15 lbs.
Strike Standard: 575
Subtype: Delayed Egress Exit Devices
Trim Part No: Less Trim
Trim Type: Less Trim
Type: Exit Devices
Ul Listing: UL 305
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 3
