PHI ELR2303 630 36 RHR Grade 1 MTS Exit Device Instructions
PHI ELR2303 630 36 RHR Grade 1 Mts Exit Device offers a robust solution for various commercial applications, featuring a Grade 1 Mortise Exit Device with a wide stile pushpad design. This 36-inch device is engineered for storeroom functionality, equipped with hex key dogging and electric latch retraction, ensuring ease of access while maintaining security. Its satin stainless steel finish not only enhances durability but also adds a modern aesthetic to any entryway. The Apex 2000 Series is trusted by top architects and end-users, especially in healthcare and educational facilities, due to its reliable performance and sleek design. UL listed for panic and fire hardware, it meets the stringent ANSI A156.3 Grade 1 standards, making it suitable for both single and double door applications. Designed to fit doors ranging from 1-3/4″ to 2-1/4″ thick and up to 4-0″ wide, this exit device is customizable to suit specific needs. The touchbar is conveniently positioned at 39-15/16″ from the floor. With its heavy wrought brass, bronze, or stainless steel construction, and investment cast steel chassis, this exit device guarantees long-lasting performance. Ideal for commercial installations, the PHI ELR2303 provides peace of mind with a 1-year limited warranty.
Grade 1 Mts Exit Device
Grade 1 Mortise Exit Device, Wide Stile Pushpad, 36″ Device, Storeroom Function, Hex Key Dogging, Electric Latch Retraction, Satin Stainless Steel Finish, Right Hand Reverse
The Apex 2000 Series Touchbar Style Exit Device is highly regarded by architects and end-users alike. Many of the nation’s largest healthcare and educational facilities prefer the Apex for its aesthetic design and efficient engineering. All Apex 2000 Series Exit Devices are UL listed for panic and fire hardware and are certified to ANSI A156.3 Grade 1.
For all types of single and double door applications.
Available for 1-3/4″ to 2-1/4″ thick, up to 4-0″ wide opening. For thicker door, consult factory. Furnished standard for 1-3/4″ thick, 3′-0″ wide opening.
- DEVICE – Covers ANSI A115.1 (Type 86) Mortise Lock preparation.
- DOUBLE CYLINDER – Handed, “10” Function available. Requires one rim type cylinder and one 1-1/4″ long mortise type cylinder, not furnished standard.
- BASE MATERIAL – The Cover, Touchbar, Device Channel, Lock/Hinge Side Filler and End Cap are furnished of heavy wrought Brass, Bronze or Stainless Steel. US28 Devices are furnished with Aluminum, Brass, Bronze and Stainless Steel components.
- CHASSIS – Investment Cast Steel, Zinc Dichromated.
- DOGGING – 1/4″ turn hex key dogging standard. NOT available on Fire Exit Hardware.
- TOUCHBAR HEIGHT – 39-15/16″ from floor standard.
- HANDED – Specify hand when ordering as RHRB or LHRB. Touchbar Assembly, Mortise Lock and Trim may be reversed in the field. For reversibility of complete device, mortise strike is required for the other hand.
- UL LISTED – Panic and Fire Exit Hardware. For FIRE EXIT HARDWARE Ratings see page 33. Conforms to UL10C and UBC 7-2.
- ANSI/BHMA – Devices are BHMA certified for ANSI 156.3, Grade 1.
- FINISHES – 605, 606, 612, 613, 625, 628, 630.
Attributes
Manufacturer surcharge: 7.0%
Ansi: A156.3
Baa Qualified: Yes
Base Material: Stainless Steel
Commercial Residential: Commercial
Country of origin: USA
Device Length: 36″
Device Type: Mortise
Dogging Options: Hex Key Dogging
Door Material: All Types
Door Thickness: 1-3/4″ to 2-1/4″
Door Width: 3′
Electric Options: Electric Latch Retraction
Finish: 630/US32D
Finish Family: Matte Silver
Fire Rated: No
Grade: Grade 1
Handing: Right Hand Reverse
Includes Trim: No
Installation: Commercial
Limited Warranty: 1 Year
Mechanical Function: Storeroom
Origin: USA
Pack Qty: 1
Physical Appearance: Wide Stile Pushpad
Reversible: Yes
Series: 2300 Series Apex Mortise Exit Devices
Strike Standard: S982
Subtype: Mortise Exit Devices
Type: Exit Devices
Ul Listing: UL10C
Unit of Measure: Each
