Description
PHI 2301 630 36 LHR Grade 1 MTS Exit Device Instructions
PHI 2301 630 36 LHR Grade 1 Mts Exit Device combines functionality and durability, making it an ideal choice for commercial applications. This Grade 1 Mortise Exit Device features a wide stile pushpad and is designed for exit-only functionality, ensuring a straightforward, efficient means of egress. It operates with hex key dogging for added security and is finished in a sleek satin stainless steel, which not only enhances its aesthetic appeal but also ensures longevity. Engineered to meet the needs of single and double door applications, the PHI 2301 is compatible with door thicknesses ranging from 1-3/4″ to 2-1/4″, accommodating openings up to 4-0″ wide. Its robust construction includes heavy wrought brass, bronze, or stainless steel components, ensuring it withstands high-traffic environments. UL listed for panic and fire hardware, this exit device conforms to ANSI A156.3 Grade 1 standards, providing peace of mind and reliability. The touchbar height is set at an industry-standard 39-15/16″ from the floor, and the device is handed, requiring specification upon ordering. With a limited 5-year warranty, the PHI 2301 630 is a trusted solution for safety and accessibility in various building settings.
Grade 1 Mts Exit Device
Grade 1 Mortise Exit Device, Wide Stile Pushpad, 36″ Device, Exit Only Function, Hex Key Dogging, Satin Stainless Steel Finish, Left Hand Reverse
The Apex 2000 Series Touchbar Style Exit Device is highly regarded by architects and end-users alike. Many of the nation’s largest healthcare and educational facilities prefer the Apex for its aesthetic design and efficient engineering. All Apex 2000 Series Exit Devices are UL listed for panic and fire hardware and are certified to ANSI A156.3 Grade 1.
For all types of single and double door applications.
Available for 1-3/4″ to 2-1/4″ thick, up to 4-0″ wide opening. For thicker door, consult factory. Furnished standard for 1-3/4″ thick, 3′-0″ wide opening.
- DEVICE – Covers ANSI A115.1 (Type 86) Mortise Lock preparation.
- DOUBLE CYLINDER – Handed, “10” Function available. Requires one rim type cylinder and one 1-1/4″ long mortise type cylinder, not furnished standard.
- BASE MATERIAL – The Cover, Touchbar, Device Channel, Lock/Hinge Side Filler and End Cap are furnished of heavy wrought Brass, Bronze or Stainless Steel. US28 Devices are furnished with Aluminum, Brass, Bronze and Stainless Steel components.
- CHASSIS – Investment Cast Steel, Zinc Dichromated.
- DOGGING – 1/4″ turn hex key dogging standard. NOT available on Fire Exit Hardware.
- TOUCHBAR HEIGHT – 39-15/16″ from floor standard.
- HANDED – Specify hand when ordering as RHRB or LHRB. Touchbar Assembly, Mortise Lock and Trim may be reversed in the field. For reversibility of complete device, mortise strike is required for the other hand.
- UL LISTED – Panic and Fire Exit Hardware. For FIRE EXIT HARDWARE Ratings see page 33. Conforms to UL10C and UBC 7-2.
- ANSI/BHMA – Devices are BHMA certified for ANSI 156.3, Grade 1.
- FINISHES – 605, 606, 612, 613, 625, 628, 630.
Attributes
Manufacturer surcharge: 7.0%
Ansi: A156.3
Baa Qualified: Yes
Base Material: Stainless Steel
Commercial Residential: Commercial
Country of origin: USA
Device Length: 36″
Device Type: Mortise
Dogging Options: Hex Key Dogging
Door Material: All Types
Door Thickness: 1-3/4″ to 2-1/4″
Door Width: 3′
Finish: 630/US32D
Finish Family: Matte Silver
Fire Rated: No
Grade: Grade 1
Handing: Left Hand Reverse
Includes Trim: No
Installation: Commercial
Limited Warranty: 5 Years
Mechanical Function: Exit Only
Origin: USA
Pack Qty: 1
Physical Appearance: Wide Stile Pushpad
Reversible: Yes
Series: 2300 Series Apex Mortise Exit Devices
Strike Standard: S982
Subtype: Mortise Exit Devices
Type: Exit Devices
Ul Listing: UL10C
Unit of Measure: Each
Resources
- 2000 Trim Instruction
- 2300 Mortise Device installation Instructions
- 2300 Series Apex Mortise Exit Devices Cut Sheet
- Apex 2000 Exit Device and Trim Illustrated Parts Catalog
- Apex 2000 Series Device with MLR Option FAQ
- Apex 2000 Series Exit Devices
- Apex 2000 Series Sell Sheet
- Exit Devices
- Filler Plate Installation Instructions
- MLR Exit Device
- Precision 2000 Series Catalog
