Description
Yale 6130FED L8 B 36 BSP LHR Grade 1 MTS Exit Device Instructions
Yale 6130FED L8 B 36 BSP LHR Grade 1 Mts Exit Device combines robust construction with modern aesthetics, making it an ideal choice for high-traffic commercial environments. This Grade 1 Mortise Exit Bar features a wide stile pushpad designed for doors ranging from 30″ to 36″ in width, ensuring easy access while maintaining security. The device is fire-rated, offering peace of mind in emergency situations. The Yale 6000 Series exit device is engineered for durability, featuring a heavy-duty aluminum rail and an architecturally finished touch bar available in five appealing finishes. With a touchbar monitor switch, this device enhances user experience by providing intuitive operation. Its less dogging feature ensures that the exit remains accessible without compromising safety. Designed for commercial applications, the Yale 6130FED is certified to ANSI/BHMA A156.3 Grade 1 standards, ensuring reliability and performance. The device is suitable for both metal and wood doors with a thickness of 1-3/4″. The left-hand reverse handing makes it versatile for various configurations. With a 10-year limited warranty, this exit device promises durability and peace of mind. Elevate your security solutions with the Yale 6130FED, where functionality meets style.
Grade 1 Mts Exit Device
Grade 1 Mortise Exit Bar, Wide Stile Pushpad (4-1/2″ or Wider), Less Dogging, 30″ – 36″ Door Opening Width, Entry By Lever, Less Trim, Fire Rated Device, Touchbar Monitor Switch, Black Suede Powder Coat Finish, Left Hand Reverse
With its robust, modern design and smooth, quiet operation, the Yale 6000 Series exit device provides an attractive solution that can withstand the rigors of multi-family, retail, office and other commercial exits. The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any decor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.
Robust, modern design and smooth, quiet operation – for multi-family, retail, office and commercial exits.
The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any décor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any décor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.
- ANSI/BHMA A156.3 Grade 1 Certified
- Available as rim, mortise, SquareBolt®, surface vertical rod and concealed vertical rod in wide or narrow stile configurations
- Highly durable aluminum rail design with architecturally finished touch bar in 5 finishes
- Heavy duty, angled end cap design protects rail, eliminates catch points and reduces damage
- Available in 13 mechanical functions and 11 electromechanical functions
- Available with standard or Reflections® decorative levers
- Complete offering of mechanical and electromechanical solutions
- Available with Microshield® antimicrobial coating
- Warranty: 10 years
Attributes
Ansi: ANSI/BHMA A156.3 Grade 1
Commercial Residential: Commercial
Device Length: 36″
Device Type: Mortise
Dogging Options: Less Dogging
Door Material: Metal or Wood
Door Thickness: 1-3/4″
Door Width: 30″ – 36″
Finish: BSP
Finish Family: Black
Fire Rated: Yes
Fire Rating: Yes {Variable}
Grade: Grade 1
Handing: Left Hand Reverse
Includes Cylinders: No
Includes Trim: No
Installation: Commercial
Limited Warranty: 10 Years
Mechanical Function: Classroom
Minimum Stile Size: 4-1/2″
Pack Qty: 1
Physical Appearance: Wide Stile Pushpad
Reversible: No
Series: Yale 6000 Series Exit Devices
Strike Standard: 798
Subtype: Mortise Exit Devices
Switch Type: Touchbar Monitor
Trim Type: Lever
Type: Exit Devices
Unit of Measure: Each
Resources
- 2023 Yale Commercial Price Book (effective 4.17.2023)
- 6000 Series Exit Devices Catalog
- Yale 6000 Series Exit Devices Cut Sheet
- Yale Commercial Finishes Chart
