Description
PHI MLR2603 613 36 Grade 1 Narrow CVR Exit Device Instructions
PHI MLR2603 613 36 Grade 1 Narrow CVR Exit Device is a top-tier solution for all metal single and double door applications. This Grade 1 concealed vertical rod exit device features a narrow stile pushpad design and a storeroom function, ensuring optimal security without compromising aesthetics. With a length of 36 inches and a dark oxidized satin bronze oil-rubbed finish, it seamlessly blends with various architectural styles while providing durability and elegance. Engineered for efficiency, this exit device boasts motorized latch retraction and is field reversible, accommodating various installation needs. It is UL listed for panic and fire hardware and certified to ANSI A156.3 Grade 1, ensuring compliance with safety standards. The device is suitable for door thicknesses ranging from 1-3/4 inches to 2-1/4 inches and can fit openings up to 4 feet wide by 10 feet high, making it versatile for commercial use. The robust construction includes an investment cast steel chassis and stainless steel top latchbolt, delivering reliable performance. With a 5-year limited warranty and available dogging options, the PHI MLR2603 exit device represents a dependable choice for professionals seeking safety and style in one efficient package.
Grade 1 Narrow CVR Exit Device
Grade 1 Concealed Vertical Rod Exit Device, Narrow Stile Pushpad, 36″ Device, Storeroom Function, Less Dogging, Motorized Latch Retraction, Dark Oxidized Satin Bronze Oil Rubbed Finish, Field Reversible
The Apex 2000 Series Touchbar Style Exit Device is highly regarded by architects and end-users alike. Many of the nation’s largest healthcare and educational facilities prefer the Apex for its aesthetic design and efficient engineering. All Apex 2000 Series Exit Devices are UL listed for panic and fire hardware and are certified to ANSI A156.3 Grade 1.
For all types of metal single and double door applications.
Available for 1-3/4″ to 2-1/4″ thick, up to 4′-0″ wide by 10′-0″ high openings. For thicker doors, consult factory. Furnished standard for 1-3/4″ thick, 3′-0″ wide by 6′-8″ to 8′-0″ high openings.
- FUNCTIONS – A Universal Exit Device. Add Trim for desired function.
- BASE MATERIAL – Side Filler and End Cap are furnished of heavy wrought Brass, Bronze or Stainless Steel. 628 Devices are furnished with Aluminum, Brass, Bronze and Stainless Steel components.
- CHASSIS – Lock Stile Assembly – Investment Cast Steel, Zinc Dich-romated.
- TOP LATCHBOLT – Stainless Steel, Deadlocking, 3/4″ throw.
- TOP STRIKE – No. S519 Surface applied, Investment Cast Stainless Steel, Black Powder Coated.
- BOTTOM STRIKE – No. S460, Flush mounted, Steel, Black Powder Coated.
- DOGGING – 1/4″ turn hex key dogging standard. NOT available on Fire Exit Hardware.
- TOUCHBAR HEIGHT – 39-15/16″ from floor standard. Specify required height if other than standard.
- UL LISTED – Panic and Fire Exit Hardware. Conforms to UL10C and UBC 7-2.
- ANSI/BHMA – Devices are BHMA certified for ANSI 156.3, Grade 1.
- FINISHES – 605, 626, 612, 613, 625, 628, 630.
- CYLINDERS – Rim Type for “03” function, 1-1/4″ Long Mortise Type for “08” function. Cylinders are not furnished standard. Specify when required.
Attributes
Manufacturer surcharge: 7.0%
Ansi: A156.3
Baa Qualified: Yes
Base Material: Bronze
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Rim
Device Length: 36″
Device Type: Concealed Vertical Rod
Dogging Options: Less Dogging
Door Material: Metal
Door Thickness: 1-3/4″
Door Width: 3′
Electric Options: Motorized Latch Retraction
Finish: 613/US10B
Finish Family: Dark Bronze
Fire Rated: No
Grade: Grade 1
Handing: Field Reversible
Includes Trim: No
Installation: Commercial
Limited Warranty: 5 Years
Mechanical Function: Storeroom
Origin: USA
Pack Qty: 1
Physical Appearance: Narrow Stile Pushpad
Reversible: Yes
Series: 2600 Series Apex Narrow Stile Concealed Vertical Rod Exit Devices
Strike Bottom: S460
Subtype: Concealed Vertical Rod Exit Devices
Top Strike: S519
Type: Exit Devices
Ul Listing: UL10C
Unit of Measure: Each
