Description
Von Duprin CD35AEO 3 315 Grade 1 Narrow Rim Exit Device 711
Von Duprin CD35AEO 3 315 Grade 1 Narrow Rim Exit 711 combines durability and functionality, making it an ideal choice for commercial applications. Designed as a Grade 1 Rim Exit Device, this unit features a narrow stile pushpad and a 36″ device length, ensuring a seamless fit for single and double doors, including those with mullions. The cylinder dogging option provides added security, while the black anodized aluminum finish enhances its aesthetic appeal. This exit device is UL listed for panic exit hardware and meets ANSI A156.3 – 2014 standards, ensuring reliability and safety in emergency situations. With a non-handed design, installation is straightforward, allowing for flexible usage across various door styles. The deadlocking latch bolt boasts a ¾” throw, providing robust security. Key specifications include a mechanism case measuring 2 1/4″ x 2 1/4″ and a projection of 3 13/16″ when the pushbar is neutral. The device accommodates door thicknesses of 1-3/4″ and is compatible with a wide range of door materials. Backed by a three-year limited warranty, the Von Duprin CD35AEO 3 315 is a reliable choice for ensuring safe and efficient exit routes in commercial settings.
Grade 1 Narrow Rim Exit 711
Grade 1 Rim Exit Bar, Narrow Stile Pushpad, 36″ Device, Exit Only, Cylinder Dogging, Less Cylinder, Black Anodized Aluminum Finish, Non-Handed
33A and 35A for all types of single and double doors with mullion, UL listed for panic exit hardware. Devices are ANSI A156.3 â 2014 Grade 1. The 35A has a smooth mechanism case and the 33A has grooved case. The rim device is non-handed except when the SS (signal switch) option is used. See opposite page for available outside trim and device functions.
Devices are ANSI A156.3 – 2001 Grade 1.
The 35A has a smooth mechanism case andrim device is non-handed except when the SS (signal switch) option is used.
- Device lengths: 3′ 2′ 4″ to 3′ (711mm to 914 mm) Door size 4′ 2’10” to 4′ (864 mm to 1219 mm)
- Door size: Device centerline from finished floor 39 13/16″ (1011 mm) 39 11/16″ (1008 mm) with Mullion
- Center case dimensions: 8 3/16″ x 1 9/16″ x 2 13/32″ (208mm x 40mm x 62mm)
- Mechanism case dimensions: 2 1/4″ x 2 1/4″ (57mm x 57mm)
- Projection: Pushbar Neutral – 3 13/16″ (97 mm) Pushbar Depressed – 3 1/16″ (78 mm)
- Latch bolt: Deadlocking, 3 /4″ (19mm) throw
- Fasteners & sex bolts (SNB): Includes 13 /4″ (44mm) – 2 1/4″ (57mm) wood & metal doors #425 SNB furnished standard for end case #325 SNB furnished standard for EO (exit only device)
Attributes
Manufacturer surcharge: 4.5%
Accessible: No
Ada Compliance: No
Ansi: ANSI A156.3 – 2014
Baa Qualified: Yes
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Non-Keyed
Device Length: 36″
Device Type: Rim
Dogging Options: Cylinder Dogging, Less Cylinder
Door Material: All Types
Door Thickness: 1-3/4″
Door Width: 2’4″ – 3′
Finish: 315/335
Finish Family: Black
Fire Rated: No
Fire Rating: No
Grade: Grade 1
Handing: Non-Handed
Includes Trim: No
Installation: Commercial
Limited Warranty: 3 Years
Mechanical Function: Exit Only
Minimum Stile Size: 1-3/4″
Origin: USA
Pack Qty: 1
Physical Appearance: Narrow Stile Pushpad
Series: 35A Series Rim Exit Device
Strike Standard: 1439
Subtype: Rim Exit Devices
Trim Type: Less trim
Type: Exit Devices
Unit of Measure: Each
