Description
Sargent LC-8224 LNJ 26D Grade 1 Room Door with Deadbolt
Sargent LC-8224 LNJ 26D Grade 1 Room Door with Deadbolt delivers unmatched strength and durability, setting a high standard among mortise locks. Exceeding ANSI/BHMA A156.13 Series 1000 Grade 1 standards, it stands as one of the most robust options available. This Grade 1 room door mortise lock features a J-lever design with an LN rose, field reversible handing, and an ASA strike, all presented in a sleek satin chrome finish. Constructed with premium components, the Sargent LC-8224 ensures maximum security and performance. It is UL-cUL listed for three-hour fire doors and windstorm applications, making it suitable for a variety of environments, from offices to hospitals. The lock is designed for flexibility, offering 58 different functions and a choice of six lever designs and 14 architectural finishes to match your style. Featuring a combination latch and bolt with a ¾ inch latch and a 1-inch deadbolt, this mortise lock is not just reliable but also easy to install and maintain. Backed by a 10-year warranty and patented construction, the Sargent LC-8224 is the ideal solution for those who prioritize security and aesthetics in their door hardware.
Grade 1 Room Door wDeadbolt
Grade 1 Room Door Mortise Lock, J – Lever, LN – Rose, Field Reversible, Less Cylinder, ASA Strike, Satin Chrome
When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
Constructed with the highest quality components to provide maximum security, durability and performance.
Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available.
Features:
- ANSI/BHMA Grade 2 certified for cycle and strength requirements
- UL-cUL listed for three-hour fire doors and windstorm applications
- Thru-bolted lever trim and strengthened cylinder retainer
- Available with security key systems (Degree, Signature, KESO, and XC)
- Available in 58 different functions, including electromechanical, security (freewheeling, security escutcheon, anti-vandal pull trim) and monitoring
- 6 lever designs, 2 roses/escutcheons designs, and 14 architectural finishes offered
- Available with behavioral health trim
- 10-year warranty
- Patented design and construction
Benefits:
- Strength & Reliability: Exceeds independent testing, making it the most durable mortise lock in the industry.
- Security: Security features provide resistance against unauthorized entry and vandalism.
- Flexibility & Aesthetics: Visual designwith a variety of functions, lever designs and architectural finishes match a wide range of styles and make it perfect for all types of applications (such as offices, hospitals, behavioral health environments, schools/universities).
- Ease of Installation & Maintenance: Multifunctional lockbody makes switching functions easy and reduces inventory requirements.
Attributes
Ansi Function: F21 – Entry Office
Baa Qualified: Yes
Bolt Projection: 3/4 In. Latch, 1 in. Deadbolt
Country of origin: USA
Cylinder Type: Less Cylinder
Door Thickness: 1-3/4 In.
Finish: 626/US26D
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 24-Room Door
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: J – Lever
Limited Warranty: 10 Years
Lock Face Size: 8 In. x 1-1/4 In.
Origin: USA
Pack Height: 4.38″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 227.64 in³
Pack Width: 5.63″
Roseescutcheon Design: LN – Rose
Screws: Combination
Series: 8200 Line Lever Mortise Locks
Ship Weight: 6.1 lbs.
Std Latch Backset Dim: 2-3/4 In.
Std Latch Type: Combination Latch and Bolt
Std Strike Height: 4-7/8 In.
Std Strike Number: 82-0110
Std Strike Type: ASA Strike
Std Strike Width: 1-1/4 In.
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Locks Installation Instructions
- 7900/8200 Series Mortise Locks Installation Instructions
- 8200 Line Lever Mortise Locks Cut Sheet
- 8200 Mortise Sectional Indicator Trim Template
- Sargent 8200 Series Environmental Product Declaration (EPD)
- Sargent 8200 Series Mortise Locks Sell Sheet
- Video: 8200 Series Mortise Lock Installation
