Description
Yale PB4755LN 626 Grade 1 Single Dummy Trim
Yale PB4755LN 626 Grade 1 Single Dummy Trim offers a robust solution for your commercial needs with its Grade 1 certification and durable design. This cylindrical lock features the Pacific Beach lever, crafted to provide an elegant and functional touch to any door. The non-keyed configuration ensures ease of access while maintaining a clean aesthetic, making it perfect for applications where locking is not required. Constructed for doors with a thickness ranging from 1-3/4″ to 2″, this trim is both versatile and user-friendly. The satin chrome finish adds a sleek appearance, while the non-handed design simplifies installation, accommodating various door orientations. Certified to ANSI/BHMA Grade 1 standards and UL Fire Listed, the Yale PB4755LN delivers security and peace of mind in high-traffic environments. Installation is straightforward, adhering to ANSI/BHMA A156.115 standards. With a 5-year limited warranty, you can trust the quality and performance of this product for years to come. Whether upgrading existing hardware or outfitting new construction, the Yale PB4755LN 626 Grade 1 Single Dummy Trim is an ideal choice for professionals seeking reliability and style in their door hardware solutions.
Grade 1 Single Dummy Trim
Grade 1 Single Dummy Trim Cylindrical Lock, Pacific Beach Lever, Non-Keyed, Satin Chrome Finish, Non-Handed
Yale 4700LN cylindrical locks are the idea choice for a wide variety of commercial applications where consistent quality, ease of use and installation are required at an economical price. The 4700LN Series is certified to ANSI/BHMA Grade 1 standards and is UL Fire Listed for all functions insuring reliability and peace of mind.
Your choice of a wide variety of commercial applications.
Ideal choice for a wide variety of grade 1 commercial applications where consistent quality, ease of use and installation are required at an economical price.
- Door Thickness: 1-3/4″ (44mm) to 2″ (51mm); 1-3/8″ (35mm) or 2-1/4″ (57mm), please specify on order
- Strike: ANSI 4-7/8″ x 1-1/4″ x 1-1/4″ (124mm x 32mm x 32mm) lip to center.
- Backset: 2-3/4″ (70mm)
- Handing: Non-handed
- Installation: ANSI/BHMA A156.115(-W)
- ANSI/BHMA: Certified ANSI/BHMA A156.2, Series 4000 Grade 1
- Warranty: 5 year
Attributes
Ansi: ANSI A156.2, Series 4000, Grade 1
Base Material: Brass, Bronze
Bolt Projection: 1/2″
Box Depth Fraction: 7-1/4″
Box Height Fraction: 3-3/4″
Box Width Fraction: 6-3/4″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: Non-Keyed
Cylinders Present: Non-Keyed
Door Thickness: 1-3/4″ to 2″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 55-Single Dummy Trim
Function Family: Dummy
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Lever Knob: Lever
Lever Knob Design Name: Pacific Beach
Leverknob Design: PB – Pacific Beach Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 5 Years
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer Function: Dummy Trim
Maximum Door Thickness: 2″
Minimum Door Thickness: 1-3/4″
Origin: United States
Pack Height: 3.75″
Pack Length: 7.25″
Pack Qty: 1
Pack Volume: 183.52 in³
Pack Width: 6.75″
Product Height: 3.75″
Product Length: 7.25″
Product Width: 6.75″
Projection: 3-1/2″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-1/2″ Rose Diameter
Roseescutcheon Dimensions: 3-1/2″
Screws: Combination
Series: 4700LN Grade 1 Cylindrical Lever Locks
Ship Weight: 4 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 497
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
