Description
Schlage CS210-B500BD SAT 605 PLY Lock Interconnected Lock
- Entrance Single Locking Interconnected – Deadbolt Operated by Key from Outside or by Turn Unit from Inside, Bolt Automatically Deadlocks when fully thrown
- ANSI Certified A156.12
- 1-3/4″ to 2″ Door Range
- UL Listed for 3 Hour Fire Door
- Commercial Grade 2
Attributes
Manufacturer surcharge: 4.5%
Ansi Function: F95 – Entrance
Backset: Adjustable Backsets
Bolt Projection: 1/2 In. Latch, 1 In. Deadbolt
Bolt Protection: 1/2 In. Latch, 1 In. Deadbolt
Commercial Residential: Commercial
Cylinder Type: SFIC Prep Less Core
Design: Saturn with Plymouth Plate
Door Thickness: 1-3/4 In. – 2 In.
Dust Box: None
Finish: 605/US3
Finish : Bright Brass
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 210-Entrance Single Locking
Grade: Grade 2
Hand: Not Handed
Handing: Not Handed
Installation: Commercial
Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
Latch Number: 12-340/16-260
Latch Type: Combination Latch and Bolt
Lever Knob Design: SAT – Saturn
Leverknob Design: SAT – Saturn
Pack Height: 7.75″
Pack Height 2: 11″
Pack Length: 10.5″
Pack Length 2: 15.75″
Pack Qty: 1
Pack Volume: 284.81 in³
Pack Volume 2: 1407.66 in³
Pack Width: 3.5″
Pack Width 2: 8.13″
Pbs Options: 220322826
Rose Escutcheon Design: SAT – Saturn Rose/PLY – Plymouth Escutcheon
Roseescutcheon Design: SAT – Saturn Rose/PLY – Plymouth Escutcheon
Screws: Combination
Series: CS210 Series Interconnected Locks
Ship Weight: 6.25 lbs.
Std Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
Std Latch Number: 12-340/16-260
Std Latch Type: Combination Latch and Bolt
Std Strike Number: 10-094/10-026
Std Strike Type: Square/Full Lip SQ Strike
Strike: Square Deadbolt and Square Full Lip Strikes
Strike Number: 10-094/10-026
Strike Type: Square/Full Lip SQ Strike
Subtype: Interconnected Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 4
Resources
- 2022 Schlage Commercial Price Book
- CS210 Series Interconnected Locks Cut Sheet
- How to Install the Schlage CS210 Interconnect Lock
- Schlage CS210 Series Sell Sheet
- Schlage CS210 Series Template
- Schlage Finishes Chart
- Video: CS210 Interconnect Lock Installation
- Von Duprin Finishes Chart
