Description
Sargent 2860-65G05 KB 26D Grade 2 Office Lock
Sargent 2860-65G05 KB 26D Grade 2 Office Lock offers a robust solution for your entryway needs, combining functionality and durability. Built to meet the rigorous standards of ANSI A156.2 Series 4000 Grade 2, this cylindrical lock features a sleek satin chrome finish and a B lever design that enhances both aesthetics and usability.Designed for doors ranging from 1-3/8″ to 1-3/4″ in thickness, this non-handed lock provides versatility in installation. With a standard 2-3/4″ backset and options for a 2-3/8″ backset, it seamlessly fits various door configurations. The durable steel zinc dichromate housing and brass components ensure longevity and reliable performance.Equipped with a disposable LFIC construction core and a 6-pin LA keyway cylinder, the Sargent 2860-65G05 allows for easy rekeying while providing a high level of security. The lock is also windstorm certified, making it suitable for a variety of environments.With a 10-year limited warranty and fire rating of up to 3 hours, this office lock is designed for medium-duty use in commercial applications. Elevate your building’s security with the Sargent 2860-65G05, a dependable choice for professionals and discerning homeowners alike.
Grade 2 Office Lock
Grade 2 Entrance/Office Cylindrical Lock, B Lever, LFIC Disposable Construction Core, Satin Chrome Finish, Non-handed
The SARGENT 6500 Line is a standard duty key-in-lever lock designed to exceed the requirements of ANSI A156.2 Series 4000 Grade 2.
Windstorm certified and has several function options.
- For Doors: 1-3/8″ (35mm) to 1-3/4″ (44mm) only
- Backset: 2-3/4″ (70mm) standard; 2-3/8″ (60mm) optional (20- Prefix)
- Cylindrical Housing: Steel zinc dichromate finish
- Front: Wrought brass and stainless steel;
- 2-1/4″ (57mm) x 1-1/8″(29mm)
- Strike:600 Curved Lip, Brass or Stainless Steel Standard,808 ANSI Curved Lip available (28- prefix),505 Full Lip strike available (14- prefix)
- Hand: Universal, not handed
- Latch: Brass 1/2″ (13mm) throw
- Keys: Two, nickel silver
- Cylinder: Brass, 6 pin, LA keyway standard
- Finishes : 3, 4, 10, 10B, 26, 26D
- (No Split Finish)
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile: 4-1/2″ (114mm)
Attributes
Ansi: F109
Ansi Function: F109 – Entry/Office
Application: Medium Duty Cylindrical
Base Material: Brass, Bronze
Bolt Projection: 1/2″
Bore Hole Diameter: 2-1/8″
Box Depth Fraction: 8-1/4″
Box Height Fraction: 4-1/4″
Box Width Fraction: 7-1/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: LFIC Disposable Construction Core
Cylinders Present: Single Cylinder
Door Thickness: 1-3/8″ to 1-3/4″
Dust Box: None
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 05-Entrance or Office
Function Family: Entrance/Office
Grade: Grade 2
Handing: Non-handed
Installation: Commercial
Latch Bore Diameter: 1″
Lever Knob: Lever
Lever Knob Design Name: B
Leverknob Design: B Lever
Leverknob Design Family: Curved Lever
Limited Warranty: 10 Year Warranty
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer Function: Entrance/Office
Maximum Door Thickness: 1-3/4″
Minimum Door Thickness: 1-3/8″
Origin: United States
Pack Height: 4.25″
Pack Height 2: 9″
Pack Length: 8.25″
Pack Length 2: 20.75″
Pack Qty: 1
Pack Volume: 249.82 in³
Pack Volume 2: 2801.25 in³
Pack Width: 7.13″
Pack Width 2: 15″
Pins: 6
Product Height: 4.25″
Product Length: 8.25″
Product Width: 7.13″
Projection: 2-3/8″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-3/8″ Rose Diameter
Roseescutcheon Dimensions: 3-3/8″
Screws: Wood/Machine Screws
Series: 6500-Line Bored Lever Locks
Ship Weight: 4.2 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 103121
Std Latch Type: Deadlatch
Std Strike Height: 4-7/8″
Std Strike Number: 808
Std Strike Type: ANSI Curved Lip Strike
Std Strike Width: 1-1/4″
Strike Dimensions: 1-1/4″ x 4-7/8″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: ANSI A156.2, Series 4000, Grade 2, UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 10
Resources
- 6500 Line (All Functions and Prefixes) Template
- 6500 Line Single & Double Lever Pull Installation Instructions
- 6500-Line Bored Lever Locks Cut Sheet
- 800 Strike Template
- 808 Strike for ANSI A115.2 – 28 Prefix Template
- Hurricane Resistant Bored Locks Sell Sheet
- Removal & Insertion of Sargent Plastic Construction Plugs for 6500 Installation Instructions
- Sargent Bored Lock Brochure
