Description
Sargent 28LC-65G04 KP 26D Grade 2 Storeroom Lock
Sargent 28LC-65G04 KP 26D Grade 2 Storeroom Lock offers a robust solution for securing storerooms and closets with its Grade 2 cylindrical design. This lock features a conventional less cylinder and a P lever that provides both functionality and comfort in operation. Designed to exceed the requirements of ANSI A156.2 Series 4000, it ensures durability and reliability for commercial applications. The Sargent 6500 Line is windstorm certified and offers versatility with various function options. Suitable for doors ranging from 1-3/8″ to 1-3/4″ thick, this non-handed lock simplifies installation across different door styles. The sturdy steel zinc dichromate cylindrical housing, combined with a wrought brass and stainless steel front, enhances its resilience. Key specifications include a 2-3/4″ standard backset, a 1/2″ throw brass latch, and a 6-pin brass cylinder with an LA keyway. The striking satin chrome finish (26D) adds a sleek aesthetic while ensuring corrosion resistance. Each lock comes with two nickel silver keys and is backed by a 10-year limited warranty, making it a dependable choice for medium-duty use. With UL Listing for safety and a fire rating of 3 hours, the Sargent 28LC-65G04 is designed to meet the security demands of today’s commercial environments.
Grade 2 Storeroom Lock
Grade 2 Storeroom/Closet Cylindrical Lock, P Lever, Conventional Less Cylinder, Satin Chrome Finish, Non-handed
The SARGENT 6500 Line is a standard duty key-in-lever lock designed to exceed the requirements of ANSI A156.2 Series 4000 Grade 2.
Windstorm certified and has several function options.
- For Doors: 1-3/8″ (35mm) to 1-3/4″ (44mm) only
- Backset: 2-3/4″ (70mm) standard; 2-3/8″ (60mm) optional (20- Prefix)
- Cylindrical Housing: Steel zinc dichromate finish
- Front: Wrought brass and stainless steel;
- 2-1/4″ (57mm) x 1-1/8″(29mm)
- Strike:600 Curved Lip, Brass or Stainless Steel Standard,808 ANSI Curved Lip available (28- prefix),505 Full Lip strike available (14- prefix)
- Hand: Universal, not handed
- Latch: Brass 1/2″ (13mm) throw
- Keys: Two, nickel silver
- Cylinder: Brass, 6 pin, LA keyway standard
- Finishes : 3, 4, 10, 10B, 26, 26D
- (No Split Finish)
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile: 4-1/2″ (114mm)
Attributes
Ansi: F86
Ansi Function: F86 – Storeroom
Application: Medium Duty Cylindrical
Base Material: Brass, Bronze
Bolt Projection: 1/2″
Bore Hole Diameter: 2-1/8″
Box Depth Fraction: 8-1/4″
Box Height Fraction: 4-1/4″
Box Width Fraction: 7-1/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: Less Cylinder
Cylinders Present: Single Cylinder
Door Thickness: 1-3/8″ to 1-3/4″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 04-Storeroom or Closet
Function Family: Storeroom
Grade: Grade 2
Handing: Non-handed
Installation: Commercial
Latch Bore Diameter: 1″
Lever Knob: Lever
Lever Knob Design Name: P
Leverknob Design: P Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 10 Year Warranty
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer Function: Storeroom/Closet
Maximum Door Thickness: 1-3/4″
Minimum Door Thickness: 1-3/8″
Origin: United States
Pack Height: 4.25″
Pack Height 2: 9″
Pack Length: 8.25″
Pack Length 2: 20.75″
Pack Qty: 1
Pack Volume: 249.82 in³
Pack Volume 2: 2801.25 in³
Pack Width: 7.13″
Pack Width 2: 15″
Pins: 6
Product Height: 4.25″
Product Length: 8.25″
Product Width: 7.13″
Projection: 2-3/8″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-3/8″ Rose Diameter
Roseescutcheon Dimensions: 3-3/8″
Screws: Wood/Machine Screws
Series: 6500-Line Bored Lever Locks
Ship Weight: 4.2 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 103121
Std Latch Type: Deadlatch
Std Strike Height: 4-7/8″
Std Strike Number: 808
Std Strike Type: ANSI Curved Lip Strike
Std Strike Width: 1-1/4″
Strike Dimensions: 1-1/4″ x 4-7/8″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: ANSI A156.2, Series 4000, Grade 2, UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 10
Resources
- 6500 Line (All Functions and Prefixes) Template
- 6500 Line Single & Double Lever Pull Installation Instructions
- 6500-Line Bored Lever Locks Cut Sheet
- 800 Strike Template
- 808 Strike for ANSI A115.2 – 28 Prefix Template
- Hurricane Resistant Bored Locks Sell Sheet
- Removal & Insertion of Sargent Plastic Construction Plugs for 6500 Installation Instructions
- Sargent Bored Lock Brochure
