Description
Hafele 551.54.827 Hafele Matrix Box P50 Drawer Side Runner, 92mm Height, 110 lbs Capacity
Hafele 551.54.827 Drawer Side Runner System offers an exceptional balance of strength and functionality, tailored for modern cabinetry. Designed specifically for the Hafele Matrix Box P50, this system features a drawer side height of 92 mm (3-5/8″) and a robust load-bearing capacity of up to 50 kg (110 lbs), making it ideal for various applications. Crafted from durable steel, the drawer sides are elegantly powder-coated in a sophisticated Champagne finish, while the cabinet runners are zinc plated for enhanced longevity. With a length of 600 mm (23 5/8″), this system allows for versatile installations. The innovative design includes a full extension feature, complemented by an integrated Smuso soft closing and self-closing mechanism, ensuring a smooth and quiet drawer operation. Installation is a breeze, requiring no tools for mounting and disassembly of the panel. Height and side adjustments can be conveniently made from above, allowing for precise alignment with height adjustments of ± 2.5 mm and side adjustments of ± 1.5 mm. Note that front fixing brackets are not included and must be ordered separately. Each package contains one left and one right drawer side with rear panel fitting, cabinet runners, and Häfele logo cover caps, making it a comprehensive solution for your drawer system needs.
Drawer side runner system, Hafele Matrix Box P50, drawer side height (3-5/8″) 92 mm, load bearing capacity (110 lbs) 50 kg
Load bearing capacity 50 kg, Hafele Matrix Box P50 drawer set, drawer side height 92 mm, Champagne, Length: 600 mm (23 5/8″)
Attributes
Adjustment facility: Convenient height and side adjustment from above when installed Height adjustment ± 2.5 mm Side adjustment ± 1.5 mm
Color/finish: Drawer sides: Powder coatedCabinet runner: zinc plated, Drawer sides: Powder coatedCabinet runner: zinc plated
Drawer side height: 92.00 mm
Front fixing brackets: not included
Height (inch): 3 5/8″
Installation: Mounting and disassembly of the panel without tools
Length (inch): 23 5/8″
Load bearing capacity: 50.00 kg
Material: Steel
Order reference: Please order recommended cylindrical head screw Cat. No. 013.20.930 for runner installation separately. Front fixing brackets for drawer not included in scope of delivery, please order separately.
Supplied with: 1 left and 1 right drawer side with rear panel fitting 1 left and 1 right cabinet runner 1 left and 1 right cover cap with Häfele logo relief
Type of pull out: Full extension, with integrated Smuso soft closing mechanism and self closing mechanism, with integrated rear panel fitting
Resources
- Fitting instructions for Matrix Box P 92 / 115
- Installation instructions
- TCH_Furniture_Cabinetry_Hardware_ 2022 | Page 8.8
