Description
Hafele 432.21.550 Hafele Matrix BB A45 Cabinet Ball Bearing Runners
Hafele 432.21.550 Cabinet Member, Ball Bearing Runners, Hafele Matrix Runner BB A45 offers a reliable and robust solution for your drawer systems. With a length of 250 mm, these zinc-coated steel runners are engineered for durability and performance, supporting a load-bearing capacity of up to 100 lbs. The innovative hold-in detent feature secures drawers in the fully closed position, effectively preventing any unwanted creeping open. Designed for material thicknesses of 1.2, 1.2, and 1.4 mm, the Hafele Matrix Runner is perfect for various applications, ensuring a smooth and stable operation. Measuring 12.7 mm in width and 45 mm in height (1 3/4″), this cabinet member is suitable for side installation with screw fixing for added security.These runners have been rigorously tested in accordance with ANSI/BHMA and WI Lever disconnect standards, assuring quality and reliability. The removal of the running track is made easy with a convenient release lever, enhancing user experience. Supplied in boxes of 50, the Hafele 432.21.550 is an excellent choice for both professional builders and discerning homeowners looking for high-quality furniture fittings.
Hafele – Cabinet Member, Ball Bearing Runners, Matrix Runner BB A45
Zinc 250 mm length
Tested in accordance with ANSI/BHMA and WI Lever disconnect
Hold-in detent secures drawer in fully closed position; prevents drawer from creeping open
Attributes
Area of application: For material thickness 1.2/1.2/1.4 mm
Color/finish: Zinc
Dim. ( W x H): 12.7 x 45 mm
Extension length: 250.00 mm
Height: 45.00 mm
Height (inch): 1 3/4″
Installation: Side, for screw fixing
Load bearing capacity: 100 lbs
Material: Steel
Mounting: Side clearance: (1/2″)
Nominal length: 9 13/16″
Order reference: Must order drawer members separately. Pallet quantities available upon request.
Removing the running track: With release lever
Supplied with: Cabinet Members have 50 pc/box
Version: Cabinet Member
Width: 12.70 mm
Width (inch): 1/2″
Resources
- TCH_Furniture_Cabinetry_Hardware_ 2022 | Page 8.120
