Description
Hafele 432.21.552 Hafele Matrix BB A45 Ball Bearing Cabinet Runners
Hafele 432.21.552 Cabinet Member, Ball Bearing Runners, Hafele Matrix Runner BB A45 is designed for seamless drawer functionality and durability. Measuring 350 mm in extension length, this cabinet member is constructed from robust zinc-coated steel, providing a load-bearing capacity of up to 100 lbs. It is specifically engineered for material thicknesses of 1.2, 1.2, and 1.4 mm, ensuring compatibility with a wide range of drawer configurations. This innovative runner features a hold-in detent mechanism that secures the drawer in its fully closed position, effectively preventing any unwanted opening-a crucial aspect for maintaining a tidy space. The side-mount installation allows for easy and secure screw fixing, while the release lever simplifies the process of removing the running track when needed. With dimensions of 12.7 mm in width and 45 mm in height (approximately 1 3/4 inches), the Hafele Matrix Runner BB A45 is not only functional but also compact, making it suitable for various applications. Each box contains 50 pieces, catering to larger projects, and pallet quantities are available upon request. Choose Hafele for reliable and high-performance cabinet fittings that enhance both the functionality and aesthetics of your furniture.
Hafele – Cabinet Member, Ball Bearing Runners, Matrix Runner BB A45
Zinc 350 mm length
Tested in accordance with ANSI/BHMA and WI Lever disconnect
Hold-in detent secures drawer in fully closed position; prevents drawer from creeping open
Attributes
Area of application: For material thickness 1.2/1.2/1.4 mm
Color/finish: Zinc
Dim. ( W x H): 12.7 x 45 mm
Extension length: 350.00 mm
Height: 45.00 mm
Height (inch): 1 3/4″
Installation: Side, for screw fixing
Load bearing capacity: 100 lbs
Material: Steel
Mounting: Side clearance: (1/2″)
Nominal length: 13 3/4″
Order reference: Must order drawer members separately. Pallet quantities available upon request.
Removing the running track: With release lever
Supplied with: Cabinet Members have 50 pc/box
Version: Cabinet Member
Width: 12.70 mm
Width (inch): 1/2″
Resources
- TCH_Furniture_Cabinetry_Hardware_ 2022 | Page 8.120
