Richelieu WEBKIT1242693 HAWA CLIPO 16 GPK Bypassing Sliding System for 2 Glass Cabinet Doors
Richelieu WEBKIT1242693 HAWA CLIPO 16 GPK IS Bypassing Sliding System offers an elegant solution for two inset glass cabinet doors, accommodating up to 35 lb (16 kg) per panel. This top-running sliding system is designed for inslide/inlay applications, featuring a sleek frameless design with a minimalistic horizontal aluminum extrusion at the top. The system includes a modest floor mount guide for added stability without compromising aesthetics. With a maximum door height of 55 1/8 inches and a width of up to 39 3/8 inches, this system provides flexibility for various cabinet designs. The double track options allow for either recess or surface mounting, ensuring compatibility with your installation preferences. An optional soft-close mechanism is available separately, enhancing functionality and user experience. Installation requires industrial adhesive to secure the glass panels to the aluminum track, which is provided by other sources. The system is adjustable, making it easy to fine-tune for precise alignment. Finished in satin aluminum, the HAWA CLIPO 16 GPK IS not only performs well but also complements modern interiors effortlessly. Ideal for cabinets and showcases, this sliding system is a perfect blend of form and function for any discerning builder or homeowner.
HAWA CLIPO 16 GPK IS Bypassing Sliding System for Two Inset Glass Cabinet Doors
HAWA CLIPO 16 GPK IS is a top running sliding system designed for two glass cabinet doors weighing up to 35 lb (16 kg) each for inslide/inlay applications. This is a frameless glass door system with a low profile horizontal aluminum extrusion only at the top of the glass. A modest floor mount guide is mounted to the cabinet bottom. There are different top double track options to recess or surface mount. An optional soft-close mechanism (sold separately) is available for inside the track.
Important: the minimum glass panel width must be 24 in (608 mm) for two soft-close mechanisms.
To install the glass, use an industrial adhesive to adhere the glass to aluminum provided by other sources.
Attributes
Adjustable: Yes
Application: Cabinet, Showcase
Brand: Hawa
Detailed Door Movement: Bypassing
Door Height: Max. 1 400 mm
Door Material: Glass
Door Movement: Straight Sliding
Door Position: Inset/Inlay
Door Thickness: 6 to 6.35 mm
Door Width: Max. 1 000 mm
Finish: Satin Aluminum
Load Capacity: 35.3 lb*
Number of Doors: 2
Product #: WEBKIT1242693
Product number: WEBKIT1242693
Product №: WEBKIT1242693
Roller Position: Upper
Roller Type: Axle (Bushing)
Running Track Fixing: Surface Mount
Soft- Closing: No
Track Finish: Satin Aluminum
Weight Capacity per Door: 16 kg
