Description
Hafele 403.20.010 Hawa Libra 20 Synchro H IF/VF Sliding Door Fitting Set
Hafele 403.20.010 Sliding door fitting, Hawa Libra 20 Synchro H IF/VF, set is expertly designed for effortless operation of vertical, bi-parting sliding doors. This system accommodates two synchronized wood doors, supporting a maximum weight of 44 lbs each and a width of up to 63 inches. Ideal for applications requiring smooth and efficient access, this fitting is perfect for residential and commercial spaces alike. The hardware is conveniently surface-mounted, making installation straightforward. It is important to note that both doors must be of equal weight to function effectively, with the bottom door serving as a counterweight for the top. This set includes all essential components such as sliding hardware with cam adjustment, spring-loaded rollers, door safety features, and cover caps, ensuring a complete solution right out of the box.Please remember to order the front guide track, back guide track, and cover strip separately to complete your setup. With a durable design, this system is suited for door heights of up to 1,000 mm and door thicknesses ranging from 5/8″ to 1″. Elevate your space with the Hafele Hawa Libra 20, where functionality meets style.
Sliding door fitting, Hawa Libra 20 Synchro H IF/VF, set
For vertical sliding doors with 2 synchronized, bi-parting doors, for door weights up to 44 lbs., Infront/Vorfront
For 2 wood doors that are synchronized All hardware is surface mounted
Please order front guide track, back guide track and cover strip separately
Attributes
Area of application: For 2 doors
Cabinet version: with synchronized running doors
Counterweight: The bottom door represents the counterweight for the top door, therefore both doors must be of equal weight
Door weight max.: 44 lbs
Door width max.: Max. 63″
For door height: ≤1,000 mm
For door material: wood
For door thickness: ≥16 mm
For door thickness min.: 5/8″
For door weight: ≤20 kg
For door width: ≤1,600 mm
For side panel thickness: min 16 mm
Installation: Running gear and guide for screw fixing
Material/finish: Rollers: Plastic
Number of doors: 2.00
Number of doors per system max.: 2
Number of rollers: 1.00
Order reference: In general, doors should be the same size, and must weigh the same as they need to counter balance each other
Running position: Bottom, lateral, top
Set: Set without tracks
Side panel thickness min.: 5/8″
Supplied with: 4 sliding hardware with cam adjustment 4 sliding hardware with spring 2 reverse roller 2 door safety 4 rope brackets 2 tightening bolt for rope bracket 2 pcs of rope 2 cover caps 8 covers for sliding hardware
Type of opening: linear
Resources
- CAD data
- Hawa Libra 20 H Mounting Instructions
- Installation instructions
- Manufacturer information
- TCH_Furniture_Cabinetry_Hardware_ 2022 | Page 7.103
