Description
LCN 4011T-STD RH 693 Heavy Duty Track Closer – GLBLK
LCN 4011T-STD RH 693 Heavy Duty Track Closer GLBLK delivers exceptional performance for interior doors in high-traffic environments, particularly within institutional settings. Engineered as part of the highly regarded 4010T Series, this Grade 1 door closer features a standard track design and is mounted on the pull side, accommodating a 180-degree swing. Adjustable cylinder sizes 1, 3, or 4 (set to size 1) provide versatility for various door configurations. This closer is UL and cUL listed, meeting ANSI/BHMA Grade 1 standards, ensuring reliability and durability for demanding applications. The LCN Green Dial spring force indicator simplifies adjustments, while the standard plastic cover can be customized with optional plated finishes to enhance aesthetic appeal. Designed for both commercial and residential use, the 4011T is ADA compliant and includes features tailored for high-traffic areas. With a 30-year limited warranty, you can trust in its longevity and performance. Additionally, this closer is equipped with a cold weather fluid option, making it suitable for diverse climates. Whether for new installations or replacements, the LCN 4011T-STD RH 693 Heavy Duty Track Closer stands out as a robust solution for those seeking quality and functionality.
Heavy Duty Track Closer GLBLK
4010T Series Grade 1 Door Closer, Standard Track, Pull Side Mounting, 180 Degree Swing, Adjustable Size 1, 3, or 4 (Set to 1), Plastic Cover, Right-Handed, Black Painted Finish
The 4010T is LCN’s best performing heavy duty track closer designed specifically for interior doors in institutional and other rugged high traffic applications.
The 4010T is LCN’s best performing heavy duty closer designed specifically for institutional and other rugged high traffic applications.
The 4010, 4020 and 4110 Series are heavy-duty closers that meet demands for high-traffic installations and each are designed specifically for unique mounting applications. They are UL and cUL listed, meet ANSI/BHMA Grade 1 standards and boast 30-year warranties. They feature a standard plastic cover, with optional plated finishes for the cover, arm and fasteners. They also feature the LCN Green Dial spring force indicator, which takes the guesswork out of adjustment.
- The 4010Series mounts hinge pull side.
- Sized cylinders for interior doors to 5’0” and exterior doors to 4’0”.
- Non-sized cylinder (4011) adjustable for interior doors to 4’6” and exterior doors to 3’6”.
- Closer mounts hinge side, specify right or left swinging door.
- Corner brackets available. See Options tab for options.
- 4011 cylinder meets ADA requirements.
- Standard or optional custom powder coat finish.
- Optional plated finish on metal cover, arm and fasteners.
- Optional SRI primer for installations in corrosive conditions is available with powder coat only.
- The 4010 Series is UL and cUL listed with regular or fusible link arms for self-closing doors.
- Tested and certified under ANSI Standard A156.4, Grade 1.
Attributes
Manufacturer surcharge: 4.5%
Accessible: Yes
Ada Compliance: Yes
Ansi: A156.4
Arm Type: Slide Track Arm, Standard
Baa Qualified: Yes
Closer Size: 1, 3, or 4
Cold Weather Fluid: Yes
Commercial Residential: Commercial
Country of origin: USA
Cover: Plastic
Degree Swing: 180 Deg.
Finish: 693
Finish Family: Black
Grade: Grade 1
Handing: Right-Handed
Hold Open: No
Installation: Commercial
Limited Warranty: 30 Years
Mounting Group: Hydraulic
Mounting Location: Pull Side
Mounting Style: Regular
Origin: USA
Screw Type: Self-Tapping
Series: 4010T Series Surface Mounted Closers
Ship Weight: 16 lbs.
Subtype: Surface Closers
Type: Surface
Ul Listing: UL 10C
Unit of Measure: Each
Resources
- 4010T Series Surface Mounted Closers Cut Sheet
- LCN 4000 Series Catalog
- LCN 4010 Series Cut Sheet
- LCN 4010, 4010T, 4510, 4510T Drop Plate Installation Instructions
- LCN 4010T Installation Instructions
- LCN Closers & Auto Operators Installation Guide
- LCN Closers & Automatic Operators Parts Manual
- Von Duprin Finishes Chart
