Description
HES 31023/412D606 310-2-3/4 12D Electric Strike Satin Brass Finish
Assa Abloy Electronic Security Hardware – Hes 31023/412D606 310-2-3/4 12D Electric Strike Satin Brass Finish
- Ul 10C Fire-Rated, 3 Hour Single Door (Fail Secure Only)
- ANSI/BHMA A156.31, Grade 1
- Tamper Resistant, Heavy-Duty Construction
- Endurance Rating 500,000 Cycles
- Non Handed
Attributes
Adjustability: Horizontal
Amp Draw: .51 @ 12V .25 @ 24V
Application: 3/4″ Latchbolt
Baa Qualified: Yes
Base Material: Brass
Commercial Residential: Commercial
Complete Pack Options: Complete Pack for 3/4″ throw latchbolt without deadbolt
Configuration: Centered
Country of origin: USA
Dynamic Strength (ft-lbs): 70
Endurance (cycles): 1,000,000
Faceplate Size: 9″ x 1-3/8″
Fail Safe or Fail Secure: Fail Secure|Fail Safe
Fail Safe | Fail Secure: Fail Secure
Finish: 606 Satin Brass, clear coated
Finish Family: Matte Brass
Fire Rated: Yes
Fire Rating: 3 Hours {A}
For Use With: Cylindrical Locks, Mortise Exit and Latch Locks
Frame Application: Metal or Wood
Frame Material: Metal|Wood
Function: Fail Secure
Grade: Grade 1
Holding Force: 1500 lbs.
Installation: Commercial
Keeper Size: 3/4″
Latchbolt Accommodation: 1/2″ – 1″
Limited Warranty: 5 Years
Lock Type: Cylindrical Lock|Mortise Lock|Mortise Lock with Deadbolt
Monitoring Installation: Factory Configured
Monitoring Options: Latchbolt and locking cam monitor with auxiliary switch
Operating Voltage: 12 VDC
Origin: USA
Pack Height: 2.5″
Pack Length: 12.25″
Pack Qty: 1
Pack Volume: 183.75 in³
Pack Width: 6″
Series: 310 Series
Shim Type: NA
Ship Weight: 3.2 lbs.
Strike: 310-2-3/4 12D Electric Strike
Strike Body Depth (in): NA
Strike Body Height (in): NA
Subtype: Electric Strikes
Surface Mounting: Cutting required
Tamper Resistant: Yes
Type: Electronics
Unit of Measure: Each
Upc: 740090045528
Voltage: 12|24
Warranty: SecuriCare five-year, no fault, no questions asked warranty
Resources
- 310 Series Electric Strikes Cut Sheet
- AA ESH Electric Strike Overview
- EMS Electric Strike Selector Guide
- Electric Strike Compatibility Chart
- Electric Strike Lock Cross Reference
- Electric Strike Selector Guide
- HES Electric Strike Overview Brochure
- HES Electric Strikes BHMA Grade 1 Certification
- HES FA 310 Series Electric Strike Catalog Page
- HES FA310 Electrc Strike BP1312-19700218 UL Certificate of Compliance
- HES Folger Adam 310 Electric Strikes Installation Instructions
