Description
Sargent 713-ETP-26D RHR LESS CYLINDER Classroom Exit Trim Kit, Key Locks/Unlocks, RHR Right Hand, Satin Chrome
Sargent 713-ETP-26D RHR LESS CYLINDER KIT is an essential component for enhancing security in your building’s exit systems. Designed specifically for classroom exit trim, this kit features a right-hand reverse configuration and is compatible with Sargent exit devices such as the 8313, 8713, 8913, 9713, 9813, and 9913. The durable escutcheon with a P lever ensures easy one-hand operation, making it convenient for high-traffic environments. This trim is non-handed and through-bolted to the chassis, offering superior security and resilience. Available in a sleek satin chrome finish (626/US26D), it blends seamlessly with modern aesthetics while meeting ANSI/BHMA standards. The kit allows for key locking and unlocking of the exit trim, providing flexibility and control over access. The Sargent 713-ETP-26D is part of a versatile series with multiple functions, including options for night latch, passage only, and electrified features. Its robust construction and variety of finishes make it an ideal choice for both professionals and discerning homeowners who prioritize safety without compromising style. Elevate your security solutions with this reliable and efficiently designed exit trim kit.
KIT – Classroom Exit Trim (Key Locks/Unlocks Exit Trim), Less 41 Mortise Cylinder, Escutcheon with P Lever, RHR Right Hand Reverse, 626/US26D Satin Chrome (Works with (12) 8313, 8713, 8913, 9713, 9813 and 9913)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Night latch key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 13: Key outside unlocks/locks trim #41 cylinder supplied. ANSI 08
- 15: Passage only (no cylinder). ANSI 14
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 & I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: 713-ETP-26D RHR LESS CYLINDER, 713ETP26DRHRLESSCYLINDER
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Handing: Right Handed Reverse
